DEI 7000 ESP Owner's Manual

Vehicle security system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 7000 ESP
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7000 ESP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEI 7000 ESP

Summary of Contents for DEI 7000 ESP

  • Page 1 Model 7000 ESP Owner's Guide...

  • Page 2: Limited Lifetime Consumer Warranty

    The warranty does not cover damage to the unit caused by installation or removal of the unit. DEI, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage.
  • Page 3 DEI does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this security system.

  • Page 4: Table Of Contents

    Table of Contents Limited Lifetime Consumer Warranty Standard Configuration ........2 What Is Included .

  • Page 5: Standard Configuration

    Standard Configuration controls the Arm, Disarm and Panic functions. is used for Silent Mode, Remote Valet and optional Trunk Release. controls an optional Auxiliary Output. controls another optional Auxiliary Output. pressed simultaneously control another optional Auxiliary Output. pressed simultaneously control another optional Auxiliary Output.

  • Page 6: What Is Included

    This owner’s guide should help you to get the most out of your system. Please take the time to read it thoroughly prior to using this system. Additional or replacement copies of this manual may be downloaded from the DEI ® 2001 Directed Electronics, Inc.

  • Page 7: System Maintenance

    System Maintenance This system requires no specific maintenance. Your remote control is powered either by a miniature 12V battery, type GP23A, or a lightweight 3-volt lithium battery, both of which will last approx- imately one year under normal use. Contact your dealer if you have any questions.

  • Page 8: Transmitter Functions

    Transmitter Functions The receiver uses a computer-based Learn Routine to learn the transmitter buttons. This makes it possible to assign any button on the remote transmitter to any receiver function. Two possible transmitter configurations are described in this section. Remember that there are many alternate custom configurations that can be programmed by your dealer.

  • Page 9: Expanded Configuration

    Button IV Another optional auxiliary convenience or expansion function that you may have added to your system can be activated by pressing This auxiliary output controls _____________________________. Buttons I and II Another optional auxiliary convenience or expansion function that you may have added to your system can be activated by pressing simultaneously.
  • Page 10 Button I The arming and Multi-Level Security functions are usually controlled by . Pressing for one second will arm the system. Pressing again within five seconds of arming activates Multi-Level Security. Button II Pressing for one second will disarm the system. If configured for optional progressive unlocking, pressing when disarming will only unlock the driver’s door.

  • Page 11: Using Your System

    Using Your System The remote button numbers in this manual correspond to the standard configuration unless otherwise specified. Remember, this is not the only way your transmitters can be programmed. Your transmitters may also be programmed for expanded configuration or custom configured by a dealer to meet your needs. Arming You can activate, or arm, the system by pressing for one...
  • Page 12 as fast as it does when the system is armed. The siren will chirp one time 20 seconds after the last door has been closed. The system is not actually armed at that point. The system arms and the doors lock (if connected and programmed for passive locking) at the 30-second mark, but the siren will not chirp.

  • Page 13: Arming While Driving

    Arming While Driving Your system can be armed while driving the vehicle! Simply press and hold on your transmitter for 1.5 seconds while the vehicle is running or the ignition is on. The system will chirp once and then once more to indicate that the ignition is on. The system will not respond to any input except the door triggers and the starter kill relay (if installed) will not be activated.

  • Page 14: Disarming

    Press a fourth time within five seconds: The siren chirps four times followed by a long chirp. Zones Two, Four, Five and Six are now bypassed. Press a fifth time within five seconds: The siren chirps five times followed by a long chirp. All input zones are now bypassed with the exception of Zones Seven and Eight.

  • Page 15: Disarming Without A Transmitter

    state. The system will not disarm, but rather reset. This prevents you from having to disable the system should you wish to stop the triggered sequence without visually checking the vehicle. Pressing the disarm button again, after resetting the system, will disarm the system.

  • Page 16: Ghost Switch

    Ghost Switch A Ghost Switch is actually a factory switch that already exists in your vehicle that can be set up to function as an optional protected disarm switch. Any factory switch in your vehicle may be used as long as it switches positive voltage. Your installer can help you to determine which switches will work in your vehicle.

  • Page 17: Silent Mode

    Silent Mode To temporarily turn off the arm or disarm chirps, use Silent Mode Simply press briefly before arming or disarming, and the confirmation chirp(s) will be eliminated for that one operation only. If you want the arm/disarm chirps turned off permanently, your dealer can do this for you.

  • Page 18: Remote Valet

    The status LED will light solid if you are entering Valet Mode, and it will go out if you are exiting Valet Mode. Nuisance Prevention Circuitry Your system has DEI ® ’s Nuisance Prevention prevents annoying repetitive trigger sequences due to faulty door pin switches or environmental conditions such as thunder, jack- hammers, airport noise, etc.
  • Page 19 Here’s how Nuisance Prevention Circuitry works: The alarm triggers three times. Each time, the same sensor or switch is triggering the alarm. The three triggers activate within 60 minutes of each other. NPC will interpret this pattern of triggers as false alarms. After the third trigger, NPC bypasses that sensor or switch (along with any other sensors or switches sharing the same zone) for 60 minutes.

  • Page 20: Diagnostics

    Diagnostics The microprocessor at the heart of your system is constantly mon- itoring all of the switches and sensors connected to it. It detects any faulty switches and sensors and prevents them from disabling the entire system. The microprocessor will also record and report any triggers that occurred during your absence.

  • Page 21: Table Of Zones

    Zones section). The system will retain this information in its memory, and chirp four or five times each time it is disarmed, until the next time the ignition key is turned on. Table of Zones The zone number is represented by the number of LED flashes used by the system to identify a specific input.

  • Page 22: Code Hopping

    Code-Hopping ® The receiver and transmitters each use a mathematical formula called an algorithm to change their code each time the transmitter is used. This technology has been developed to increase the security of the unit. The control unit detects what the next codes should be.

  • Page 23: Owner Recognition

    Additional installation labor may be required. Rapid Resume Logic This DEI security system is equipped with circuitry that allows the unit to remember its alarm state if power is lost and then recon- nected. If the battery is disconnected and then reconnected, the security system will power up in the same state it was in when power was lost.

  • Page 24: Programming Options

    the VRS sequence. If the unit loses power at any time during the VRS sequence, when the unit is powered back up it will automati- cally resume the VRS full trigger sequence. Programming Options Programming options control how your system performs during normal operation;...
  • Page 25 Panic mode enabled/disabled with the ignition on: Some states have laws against siren capability in a moving vehicle. Automatic Engine Disable (AED) on or off: The purpose of the feature is to protect the vehicle from being stolen at all times, regardless of whether or not the alarm is armed.
  • Page 26 If your installer is programming the security system with the DEI Bitwriter or a personal computer and the TechSoft Programmer, the full triggered response can be programmed for any duration ranging from 1 to 180 seconds.

  • Page 27: Installation Options

    Your dealer can eliminate any of these tones, resulting in a unique, easily identifiable siren sound. Siren chirps can be either full volume or 6 decibels quieter than full alarm blast. Additional installation labor may be required. Installation Options The system has many options that may require extra parts and labor.

  • Page 28: Vehicle Recovery System (Vrs )

    Any installation which allows this product to shut down a vehicle’s engine when running is contrary to the product’s design and intended usage, and DEI ® expressly disclaims any liability resulting therefrom.

  • Page 29: Arming The Vrs

    Arming The VRS To arm the VRS, press the arm button on the remote while the vehicle’s ignition is on. Once the system is armed, it will go into its triggered sequence (see below) if any door is opened and closed. If you are forced from the vehicle, the VRS system will trigger when the door is opened and then closed as you leave the vehicle.

  • Page 30: Disarming The Vrs

    From this point forward, when the ignition key is turned off, the VRS will immediately turn on the FailSafe starter kill. This will prevent the vehicle from being restarted, thus immobilizing it at that spot. Three minutes after the constant siren output begins, the flashing parking lights and the siren will stop.

  • Page 31: Glossary Of Terms

    If the system has entered the full triggered sequence (siren full volume), pressing the disarm button of the transmitter will not DRW-35 disarm VRS. You must turn the ignition to the on position and press the Valet switch. The system can also be disarmed by pressing the Ghost Switch the programmed number of times to disarm the VRS system.
  • Page 32 LED: Red light mounted somewhere in the vehicle. It is used to indicate the status of your system. It is also used to report triggers and faults in the system or sensors. Shock Sensor: This system is packaged with a DoubleGuard ®...

  • Page 33: Security & Convenience Expansions

    Security & Convenience Expansions Here we have listed only some of the many expansion options available. Please contact your dealer for a complete explanation of all the options available to you. All security and convenience expansions require additional parts and labor. Field Disturbance Sensor: An invisible dome of coverage is estab- lished by the 508D “radar”...
  • Page 34 DEI's 522T trunk release solenoid can often be added. Valet ® Start System: For the ultimate in convenience, the Valet start system can start your vehicle, monitor engine functions, and power your climate control system with a push of a button! Over- rev protection, open-hood lockout, brake pedal shutoff, and automatic timer shutoff are all included.
  • Page 35 Notes 2001 Directed Electronics, Inc. ©...

  • Page 36: Quick Reference Guide (Removable)

    QUICK REFERENCE GUIDE: To arm using your remote s You can activate, or arm, the system by pressing mitter for one second. When the system arms, you will hear a short siren sound, or chirp, and the parking lights will flash once. If the vehicle’s power door locks have been connected to the system, the doors will lock.
  • Page 37 The company behind this system is Directed Electronics, Inc. Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced elec- tronic technology, Directed Electronics is ISO 9001 registered.
