DEI 725T Owner's Manual

Dei hornet 725t car alarms: owners guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 725T
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 725T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEI 725T

Summary of Contents for DEI 725T

  • Page 1 Model 725T Owner's Guide...

  • Page 3: Limited Lifetime Consumer Warranty

    This warranty contains the entire agreement relating to warranty and supersedes all previous and contemporaneous representations or understandings, whether written or oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS CONTENTS. This warranty is void if the product has been damaged by accident, unreasonable use, neglect, improper service or other causes not arising out of defects in materials or construction.
  • Page 4 TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD- ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM- MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU- SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.

  • Page 5: Table Of Contents

    Table of Contents Standard Configuration ........2 System Maintenance .

  • Page 6: Standard Configuration

    Standard Configuration Silent Mode Disarm Auxiliary Output Pani 2002 Directed Electronics, Inc. ©...

  • Page 7: System Maintenance

    What is Included The control module A pair of two-button transmitters A Stinger ® Doubleguard (on board the control module) The Revenger ® Soft Chirp The red status LED indicator light A push-button Valet Your warranty card Important Information Congratulations on the purchase of your state-of-the-art vehicle security system.

  • Page 8: Your Warranty

    battery weakens, operating range will be reduced and the LED on the remote will light dim. Your Warranty Your warranty card must be returned within 10 days of purchase and the bar-code serial number must not be removed. If the war- ranty card is not returned you do not have a warranty.

  • Page 9: Transmitter Functions

    Transmitter Functions Button I The arm, disarm and panic functions, are usually controlled by Button II Silent Mode ™ and an optional auxiliary function, such as trunk release, are usually controlled by for less than one second before arming or disarming. Trunk release requires you to press Using Your System Arming...

  • Page 10: Passive Arming

    Passive Arming The system can also be programmed to arm itself automatically (called passive arming). If the system is programmed for passive arming, it will automatically arm 30 seconds after the ignition is turned off and the system "sees" you leave the vehicle by open- ing and closing a door.

  • Page 11: Arming While Driving

    Turning on the ignition key will trip the same two-stage response as opening a door. The optional starter kill prevents the vehicle’s starter from cranking. Arming While Driving Your system can be armed while driving the vehicle! Simply press on your transmitter for two seconds while the vehicle is run- ning.

  • Page 12: Disarming Without A Transmitter

    High Security Disarm Your system includes a High Security Disarm feature. During the triggered sequence, using the transmitter to disarm the system will only stop the triggered sequence (the siren will stop and the parking lights will stop flashing). However, the system will remain armed and the doors will stay locked.

  • Page 13: Panic Mode

    Silent Mode To temporarily turn off the arm or disarm chirps, use Silent Mode Simply press briefly before arming or disarming, and the con- firmation chirp(s) will be eliminated for that one operation only. If you want the arm/disarm chirps turned off permanently, your dealer can do this for you.

  • Page 14: Nuisance Prevention Circuitry

    The same procedure can be used to either enter or exit Valet 2. Turn the ignition on. 2. Turn the ignition off. 3. Press and release the The status LED will light steady if you have entered Valet Mode, and it will go out if you have exited Valet Mode. Remote Valet Using Remote Valet as you enter or exit the vehicle: Open any door.
  • Page 15 interpret those triggers as false alarms. After the third trigger, NPC® ignores, or bypasses, that sensor or switch (along with any other sensors or switches sharing the same zone) for 60 minutes. If the bypassed sensor tries to trigger the system while it is being bypassed, the 60-minute bypass period will start over.

  • Page 16: Diagnostics

    The microprocessor at the heart of your security system is con- stantly monitoring all of the switches and sensors that are con- nected to it. It detects any faulty switches and sensors and pre- vents them from disabling the entire system. The microprocessor will also record and report any triggers that occurred during your absence.

  • Page 17: System Status Chirps

    Disarming Diagnostics Extra disarm chirps are the Tamper Alert. If four chirps are heard when disarming, the system was triggered in your absence. If five chirps are heard, a zone was triggered so many times that Nui- sance Prevention® Circuitry has bypassed that zone. The status LED will indicate which zone was involved.

  • Page 18: Interpreting Zone Diagnostics

    Table of Zones The zone number is the number of LED flashes used by the system to identify that input. The standard input assignments are listed below, along with spaces to write in any optional sensors or switches you have had installed. Zone - Number of LED Flashes Interpreting Zone Diagnostics...

  • Page 19: Code Hopping

    Code Hopping ® The receiver and transmitters each use a mathematical formula called an algorithm to change their code each time the transmit- ter is used. This technology has been developed to increase the security of the unit. The control unit knows what the next codes should be.

  • Page 20: Programming Options

    Programming Options Programming options control what your system does during nor- mal operation, and require few or no additional parts. However, some may require additional installation labor. The factory set- tings are in bold. Active arming (only with the transmitter) or passive arming (automatic arming 30 seconds after the last door is closed).
  • Page 21 with the remote and then disarm it with the remote. You can also disarm the AED feature by turning the ignition on and pressing the Valet button once. AED is also disabled when in Valet mode. NOTE: This feature will only function if the Failsafe starter kill relay has been installed.

  • Page 22: Glossary Of Terms

    Glossary of Terms Control Unit: The “brain” of your system. Usually hidden under- neath the dash area of the vehicle. It houses the microprocessor which monitors your vehicle and controls all of the alarm's functions. Failsafe ® Starter Kill (Optional): An automatic switch controlled by the security system which prevents the vehicle’s starter from cranking whenever the system is armed.
  • Page 23 Transmitter: Hand-held, remote control which operates the vari- ous functions of your system. Trigger or triggered response: This is what happens when the alarm “goes off” or “trips.” The triggered response of your system consists of 30 seconds of siren sounding and parking light flashing. Valet ®...

  • Page 24: Security & Convenience Expansions

    Security & Convenience Expansions Here we have listed only some of the many expansion options available for use with your system. Please consult your dealer for a complete list of all the options available to you. Field Disturbance Sensor: An invisible dome of coverage is estab- lished by the 508D “radar”...
  • Page 25 (An optional relay may be required.) If the factory release is not power-activated, DEI's 522T trunk-release solenoid can often be added. Power Locks: This system offers lock outputs that can control some manufacturers' power door lock systems.

  • Page 27: Quick Reference Guide

    QUICK REFERENCE GUIDE: To arm using your remote s Press for less than a second. When armed the siren chirps once and the parking lights flash once. Arming s Press of your transmitter for one second. When the system arms, you will hear a short chirp, and see the parking lights flash once.
  • Page 28 The company behind this system is Directed Electronics, Inc. Since its inception, Directed has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, Directed is ISO 9001 registered.
