  • Page 1 Model 500 ESP Owner's Guide...
  • Page 3 The warranty does not cover damage to the unit caused by installation or removal of the unit. DEI, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage.
  • Page 4 DEI does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this security system.

  • Page 5: Table Of Contents

    Table of Contents Limited Lifetime Consumer Warranty Standard Transmitter Configuration What Is Included ..........3 Important Information .

  • Page 6: Standard Transmitter Configuration

    Standard Transmitter Configuration controls the Arm function. controls the Disarm function. controls Silent Mode™and an Auxiliary Output. controls the Panic function. pressed simultaneously control an Auxiliary Output. 1999 Directed Electronics, Inc. ©...

  • Page 7: What Is Included

    What is Included 3-Channel Receiver A pair of four-button transmitters A Stinger ® Doubleguard ® dual-output shock sensor The Revenger ® Soft Chirp ® The red status LED indicator light A push-button Valet ® switch Your warranty card Failsafe ® Starter Kill ready circuitry (may require additional labor) Important Information...

  • Page 8: System Maintenance

    System Maintenance The system requires no specific maintenance. Your remote control is powered by a small, lightweight 3-volt lithium battery that will last approximately one year under normal use. When the battery weakens, operating range will be reduced and the LED on the remote will dim.

  • Page 9: Transmitter Functions

    Transmitter Functions The receiver uses a computer-based Learn Routine to learn the transmitter buttons. This makes it possible to assign any transmit- ter button to any receiver function. The transmitter initially comes programmed with Standard Configuration, but may also be customized by an authorized dealer.

  • Page 10: Using Your System

    Buttons An optional auxiliary convenience or expansion function that you have added to your system can be activated by pressing simultaneously. The auxiliary output controls _____________________________. Using Your System The buttons used in the instructions in this manual correspond to the standard configuration.
  • Page 11 The system also can be programmed to arm itself automatically (called passive arming). If the system is programmed for passive arming, it will automatically arm 30 seconds after the ignition is turned off and the system "sees" you leave the vehicle by opening and closing a door.

  • Page 12: Multi-Level Security Arming

    your transmitter if you inadvertently open the door while the system is armed, while still providing an instant response (even if the door is immediately closed). Turning on the ignition key will trip the same two-stage response as opening a door. The optional starter kill prevents the vehicle’s starter from cranking.

  • Page 13: Arming While Driving

    Pressing a fifth time within five seconds: The siren chirps five times followed by a long chirp. All input zones, except the ignition, are now bypassed. NOTE: Multi-Level Security Arming only applies to a single arming cycle. Once the system is disarmed and then re-armed, all the zones will be active again.

  • Page 14: High Security Disarm

    High Security Disarm This security system proudly offers High Security Disarm. High Security Disarm is a feature that makes it possible to silence and reset the system while it is triggering, without disarming the system. If the system is triggered, and the siren has been sound- ing for longer than six seconds, pressing on the remote transmitter will stop the trigger and return the unit to the armed...

  • Page 15: Silent Mode

    To disarm the security system, turn the ignition to the "ON" position. Press the Valet switch the preset number of times (1-5 times) within 15 seconds. The system should now disarm. If the system does not disarm, you may have waited too long; turn the ignition off and on and try again.

  • Page 16: Panic Mode

    Panic Mode If you are threatened in or near your vehicle, you can attract attention by triggering the system with your transmitter! Just press for 1 second, and you will enter Panic Mode. The siren will sound and the parking lights will flash for the programmed siren duration.

  • Page 17: Remote Valet

    Valet Mode. Nuisance Prevention ® Circuitry Your system has DEI ® ’s Nuisance Prevention prevents annoying repetitive trigger sequences due to faulty door pin switches or environmental conditions such as thunder, jack- hammers, airport noise, etc.

  • Page 18: Diagnostics

    If the bypassed sensor tries to trigger the system while it is being bypassed, the 60-minute bypass period will start over. This ensures that a sensor that continually triggers will remain bypassed. Doors are covered by NPC differently: If the alarm is triggered by an open door for three full cycles, the doors will be bypassed until the trigger ceases.

  • Page 19: Arming Diagnostics

    Arming Diagnostics If the system is armed while an input is active (door open, sensor triggering, etc.) the unit will chirp once when arming and then one more time a few seconds later. This is called Bypass Notification. NOTE: Bypass Notification will not occur when using Silent Mode chirps have been programmed OFF.

  • Page 20: Table Of Zones

    Table of Zones The zone number is the number of LED flashes used by the system to identify that input. The standard input assignments are listed below, along with spaces to write in any optional sensors or switches you have had installed. ZONE (Number of DESCRIPTION...

  • Page 21: Code-Hopping

    Code Hopping The receiver and transmitters each use mathematical formulas called algorithms to change their codes each time the transmitter is used. This technology has been developed to increase the secu- rity of the unit. The control unit knows what the next codes should be.

  • Page 22: Owner Recognition

    Owner Recognition Owner Recognition is a feature available exclusively from DEI Using a DEI ® Bitwriter, hand-held programming tool, your dealer can program many of the system settings. The programmer makes it possible to program different settings for each transmitter that is used with the system.

  • Page 23: Power Saver Mode

    Power Saver Mode Your system will automatically enter Power Saver Mode while armed or in Valet Mode, after a period of time in which no opera- tion has been performed. This lowers the current draw to prevent the system from draining the vehicle’s battery. Power Saver Mode takes over under the following conditions: Power Saver when the system is armed: After the system has been armed for 24 hours, the LED will flash at half its normal...

  • Page 24: Programming Options

    If your installer is programming the security system with the DEI Bitwriter or a personal computer and the TechSoft Programmer, ignition lock and unlock are indepen- dent features and can be programmed separately.
  • Page 25 Panic mode enabled/disabled with the ignition on: Some states have laws against siren capability in a moving vehicle. Forced passive arming on or off: If your system is programmed for passive arming and the forced passive arming feature has been programmed on, the system will passively arm after one hour, even if a protected entry has been left open.
  • Page 26 If your installer is programming the security system with the DEI Bitwriter or a personal computer and the TechSoft Programmer, the full triggered response can be programmed for any duration ranging from 1 to 180 seconds.

  • Page 27: Installation Options

    Installation Options The system has many options that may require extra parts and labor. Some of the possibilities are listed here. Progressive unlocking: In most cars with electric power door locks, the system can be configured so that when the system is disarmed, only the driver’s door unlocks.

  • Page 28: Vehicle Recovery System

    Any installation which allows this product to shut down a vehicle's engine when it is running is contrary to the product’s design and intended usage, and DEI ® hereby expressly disclaims any liability resulting therefrom.

  • Page 29: Arming The Vrs

    Arming the VRS ® To arm the VRS ® , turn the ignition to the ON position and press the arm button on the remote transmitter for one second. The parking lights will flash and the siren will chirp once. This can be done before driving or while driving the vehicle.

  • Page 30: Disarming The Vrs

    Fifteen seconds after the siren chirps begin, the siren’s output will change to a continuous blast. From this point on, when the ignition key is turned off, the VRS ® will immediately turn on the starter kill. This will prevent the vehicle from being restarted, thus immobilizing it at that spot.
  • Page 31 1. Turn the ignition on. 2. Press the disarm button on the transmit- ter for one second. The lights will flash and the siren will chirp twice. If the system has entered the triggered sequence (siren has begun chirping), pressing the disarm button of the transmitter will not disarm VRS.

  • Page 32: Glossary Of Terms

    Glossary of Terms Control Unit: The "brain" of your system. Usually hidden underneath the dash area of the vehicle. It houses the microprocessor which mon- itors your vehicle and controls all of the security system's functions. Failsafe ® Starter Kill: An automatic switch controlled by the secu- rity system which prevents the vehicle’s starter from cranking whenever the system is armed.
  • Page 33 Transmitter: Hand-held, remote control which operates the various functions of your system. Trigger or Triggered Sequence: This is what happens when the alarm "goes off" or "trips". The triggered response of your system consists of 30 seconds of siren sounding and parking light flashing. Valet ®...

  • Page 34: Security & Convenience Expansions

    Security & Convenience Expansions Here we have listed only some of the many expansion options available. Please contact your dealer for a complete explanation of all the options available to you. Audio Sensor: Metal on glass, glass cracking, and breaking glass each produce distinctive acoustic signatures.
  • Page 35 DEI security system. Using the 820T, many of the security and convenience fea- tures of your DEI security system can be operated from any touch- tone telephone. 1999 Directed Electronics, Inc.
  • Page 36 Notes 1999 Directed Electronics, Inc. ©...

  • Page 37: Quick Reference Guide (Removable)

    QUICK REFERENCE GUIDE: To arm using your remote You can activate, or arm, the system by pressing for one second. When the system arms, you will hear a short siren sound, or chirp, and the parking lights will flash once. If the vehicle’s power door locks have been connected to the system, the doors will lock.
  • Page 40 The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world.
