DEI 720T Owner's Manual

Dei hornet 720t car alarms: owners guide

Advertisement

Quick Links

Model 720T
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DEI 720T

  • Page 1 Model 720T Owner's Guide...
  • Page 3: Limited Lifetime Consumer Warranty

    This warranty contains the entire agreement relating to warranty and supersedes all previous and contemporaneous representations or understandings, whether written or oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS CONTENTS. This warranty is void if the product has been damaged by accident, unreasonable use, neglect, improper service or other causes not arising out of defects in materials or construction.
  • Page 4 TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD- ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM- MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU- SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.
  • Page 5: Table Of Contents

    Table of Contents Limited Lifetime Consumer Warranty ......i What Is Included .
  • Page 6: Transmitter Configuration

    Transmitter Configuration Disarm Panic Shock Sensor Adjustment Silent Mode Shock Sensor Adjustment 1999 Directed Electronics, Inc. ©...
  • Page 7: What Is Included

    What is Included The control module A pair of two-button transmitters The siren and voice command module, on-board the control module A Stinger ® Doubleguard ® dual-stage shock/impact sensor, on- board the control module The red status LED indicator light Important Information Congratulations on the purchase of your state-of-the-art vehicle security system.
  • Page 8: System Maintenance

    Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this device. System Maintenance The system requires no specific maintenance. Your remote control is powered by a miniature 12V battery, type GP23A, that will last approximately one year under normal use.
  • Page 9: Using Your System

    Using Your System Arming You can turn on, or arm, the system by pressing mitter for one second. When the system arms, the voice command module will announce “SYSTEM ARMED” and the parking lights will flash once (optional). While the system is armed, the status LED will flash approximately twice per second, indicating that the sys- tem is actively protecting your vehicle.
  • Page 10: Disarming

    Disarming To turn off, or disarm the system, press again. The voice com- mand module will announce “SYSTEM DISARMED” and the parking lights will flash twice (optional). High Security Disarm Your system includes a High Security Disarm feature. During the trigger sequence, using the remote transmitter to disarm the sys- tem will only stop the trigger sequence (the siren will stop);...
  • Page 11: Panic Mode

    Panic Mode If you are threatened in or near your vehicle, you can attract attention by triggering the system with your transmitter! Just press for 1.5 seconds, and you will enter Panic Mode. The siren will sound for 30 seconds. To stop Panic Mode at any time, press on the transmitter again.
  • Page 12: Adjusting The Shock Sensor Full Trigger

    If the current setting is acceptable, do nothing and the unit will exit shock sensor adjustment mode. If the current setting is unacceptable, press the sensitivity or to increase the sensitivity. Each time is pressed, the unit will emit one chirp and the sensitiv- ity is decreased one step.
  • Page 13: Code Hopping

    step. There are 16 possible settings. When the maximum or minimum setting is achieved, the siren will emit a long chirp. NOTE: If more than five seconds elapse without an adjustment, shock sensor adjustment mode will be exited. Repeat steps 1 through 3 to make additional adjustments.
  • Page 14: Programming Options

    Programming Options Programming options control what your system does during nor- mal operation, and require few or no additional parts; however, some options may require additional installation labor. The facto- ry settings are in bold. Voice command or chirps. You can choose whether you want the system to issue voice commands or chirps to protect your vehicle.
  • Page 15: Glossary Of Terms

    FailSafe ® Starter Kill: An automatic switch controlled by the secu- rity system which prevents the vehicle’s starter from cranking whenever the system is armed. The vehicle is never prevented from cranking when the system is disarmed, in Valet ® mode, or should the starter kill switch itself fail.
  • Page 16 Siren: Noise generating device on-board the control unit. It is responsible for generating the voice announcements and chirps that you hear, as well as the tones you hear while the alarm is trig- gered. Transmitter: Hand-held, remote control which operates the vari- ous functions of your system.
  • Page 17: Quick Reference Guide (Removable)

    QUICK REFERENCE GUIDE: To arm using your remote s You can activate, or arm, the system by pressing for one second. When the system arms, the voice command module will announce “SYSTEM ARMED” and the parking lights will flash once (optional).
  • Page 20 The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world.
