This warranty contains the entire agreement relating to warranty and supersedes all previous and contemporaneous representations or understandings, whether written or oral. IN ANY EVENT, DEI IS NOT LIABLE FOR THE THEFT OF THE VEHICLE AND/OR ITS CONTENTS. This warranty is void if the product has been damaged by accident, unreasonable use, neglect, improper service or other causes not arising out of defects in materials or construction.
Page 4
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WARRANTIES ARE EXCLUD- ED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COM- MERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLU- SION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.
What is Included The control module A pair of two-button transmitters The red status LED indicator light A push-button Valet ® switch Your warranty card Important Information This owner’s guide should help you to get the most out of your sys- tem.
FCC/ID Notice This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interfer- ence received, including interference that may cause undesired op- eration.
Standard Configuration The standard configuration is how the transmitters come pro- grammed initially. If you would like a custom configuration, see your dealer. Button The lock/arm, unlock/disarm, and panic functions are controlled . Pressing for one second will alternately lock/arm or unlock/disarm.
Using Your System Locking/Arming Pressing for one second will lock the doors. The red LED will begin to flash once per second. If connected, the vehicle's horn will honk and the parking lights will flash once to confirm locking of the doors. If the ignition is turned on while the vehicle is locked/armed, the horn will honk and the parking lights will flash (if connected).
Unlocking/Disarming To unlock the doors of the vehicle, press vehicle’s horn (if connected) will honk twice, and the parking lights will also flash twice (if connected). The red LED will go out, unless the system is programmed for passive mode. If programmed for passive mode, the LED will begin to flash rapidly when the sys- tem is disarmed.
Silent Mode Use the Silent Mode ™ to temporarily turn off the lock/arm or unlock/disarm confirmation honks by briefly pressing either locking/arming or unlocking/disarming the system. The confirmation honk(s) will then be eliminated for that one opera- tion only. To permanently turn off the lock/arm and unlock/disarm confirmation honks, contact your installation dealer.
To enter or exit Valet ® Mode with the Valet Turn ignition to the “on” position and then to the “off” position. Press and release the Valet within 10 seconds. The status LED will light solid if you have entered Valet ®...
Programming Options Programming options control what your system does during normal operation, and require few or no additional parts. However, some programming options may require additional installation labor. The way your system behaves during everyday use is programma- ble. The following is a list of the program settings, with the facto- ry settings in Bold: Passive mode or active mode.
Owner Recognition Owner Recognition is a feature available exclusively from DEI Using a DEI ® Bitwriter hand-held programming tool, your dealer can program many of the system settings. The programmer makes it possible to program different settings for each transmitter that is used with the system.
Page 16
Power Trunk Release: This expansion option allows you to oper- ate a factory power release for the vehicle's trunk or hatch. If the factory release is not power-activated, DEI's 522T trunk-release solenoid can often be added. Failsafe ®...
Glossary of Terms Control Unit: The “brain” of your system. Usually hidden under- neath the dash area of the vehicle. It houses the microprocessor which monitors your vehicle and controls all of the alarm’s func- tions. LED: Red light mounted somewhere in the vehicle. It is used to indicate the status of your system.
QUICK REFERENCE GUIDE: To lock/arm using your transmitter Pressing for one second will lock the doors. The red LED will begin to flash once per second. The optional Failsafe the vehicle’s starter from cranking if it has been installed. The vehicle’s horn (if connected) will honk and the parking lights will flash once to confirm arming of the system.
Page 20
Since its inception, DEI® has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered.
