Page 3
The warranty does not cover damage to the unit caused by installation or removal of the unit. DEI, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage.
Page 4
DEI does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this security system.
What is Included The control unit A pair of two-button transmitters A Stinger® Doubleguard® dual-stage shock/impact sensor The Revenger® Soft Chirp® six-tone programmable siren The red Status LED indicator light A push-button Valet® switch Your warranty card Failsafe® starter-kill-ready circuitry (may require additional labor) Important Information FCC/ID Notice...
Your System Congratulations on the purchase of your state-of-the-art vehicle security system. This system has been designed to provide years of trouble-free operation. Due to the complexity of this system, it must be installed by an authorized dealer only. Installation of this product by anyone other than an authorized dealer voids the war- ranty.
Transmitter Functions The receiver uses a computer-based Learn Routine to learn the transmitter buttons. This makes it possible to assign any remote transmitter button, or combination of buttons, to any receiver function. The transmitter initially comes programmed with Standard Configuration, but may also be customized by an autho- rized dealer.
Using Your System Arming You can turn on, or arm, the system by pressing mitter for one second. When the system arms, you will hear a short siren sound, or chirp, and see the parking lights flash once. If the vehicle’s power door locks are controlled by the system, the doors will lock.
When armed, your vehicle is protected in the following ways: Light impacts will trigger the Warn Away® signal. When trig- gered, the siren will chirp and the parking lights will flash for a few seconds. Heavy impacts will trigger the system. The trigger sequence is 30 seconds of constant siren and flashing parking lights.
Disarming To turn off, or disarm the system, press again. You will hear two chirps, and the parking lights will flash twice. If power locks are controlled by the system, the doors will unlock. If the siren chirps either four or five times when disarming, see Diagnostics section.
To disarm without a transmitter: Turn on the ignition. Push the Valet switch within 15 seconds. The sys- tem should now disarm. If it does not, you may have waited too long, so turn the ignition off and on and try again.
Valet® Mode You can prevent your system from automatically arming and trig- gering by using Valet Mode. This is very useful when washing the vehicle or having it serviced. In Valet Mode, the system will not arm, even with the transmitter, but all convenience functions (door locks, trunk release, etc.) will work normally.
Nuisance Prevention® Circuitry Your system has DEI's Nuisance Prevention® Circuitry (NPC prevents annoying repetitive trigger sequences due to faulty door pin switches or environmental conditions such as thunder, jack- hammers, airport noise, etc. Here's how it works: Let's say the alarm triggers three times. Each time, the same sensor or switch is triggering the alarm.
Diagnostics The microprocessor at the heart of your system is constantly mon- itoring all of the switches and sensors connected to it. It detects any faulty switches and sensors and prevents them from disabling the entire system. The microprocessor will also record and report any triggers that occurred during your absence.
chirps are heard, a zone was triggered so many times that Nuisance Prevention® Circuitry has bypassed that zone. In either case, the Status LED will indicate which zone was involved (see Table of Zones section). The system will retain this information in its memory, and chirp four or five times each time it is disarmed, until the next time the ignition key is turned on.
Code-Hopping The receiver and transmitters each use a mathematical formula called an algorithm to change their code each time the transmit- ter is used. This technology has been developed to increase the security of the unit. The control unit knows what the next codes should be.
Page 19
Arming/disarming confirmation chirps on or off. Passive door locking (with passive arming) or active door locking (only when arming with the transmitter). This feature only works if passive arming has been selected for step one. The ignition-switch-controlled door-locking feature on or off. With this feature on, the doors will lock 3 seconds after the key is turned on, and unlock when the key is turned off.
even if a protected entry has been left open. If a door has accidentally been left ajar when leaving the vehicle, forced passive arming ensures that the system will arm in one hour. NOTE: When forced passive arming occurs, the entry point that has been left open, and anything connected to the same zone, is bypassed and cannot trigger the system.
Page 21
Input: A physical connection to the system. An input can be pro- vided by a sensor, pinswitch or to existing systems in the vehicle, such as ignition or courtesy lights. LED: Red light mounted somewhere in the vehicle. It is used to indicate the status of your system.
Zone: A zone is a separate input that the alarm can recognize as unique. Each input to the system is connected to a particular zone. Often two or more inputs may share the same zone. Security & Convenience Expansions Here we have listed only some of the many expansion options available.
Page 23
(An optional relay may be required.) If the factory release is not power-activated, the DEI's 522T trunk-release solenoid can often be added. Power Locks: This system offers lock outputs that can control some manufacturers' power door lock systems.
QUICK REFERENCE GUIDE: Arming Press of your transmitter for one second. When the system arms, you will hear a short chirp, and the parking lights will flash once. If the vehi- cle’s power door locks are controlled by the system, the doors will lock. Arming While Driving Press on your transmitter while the vehicle is running.
Page 28
The recipient of more than 20 patents in the field of advanced electronic technology, DEI is ISO 9001 registered. Quality Directed Electronics products are sold and serviced throughout North America and around the world.
