DEI Automate 415 Owner's Manual

Dei automate 415: owners guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model 415
Owner's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Automate 415 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEI Automate 415

Summary of Contents for DEI Automate 415

  • Page 1 Model 415 Owner’s Guide...

  • Page 2: Limited Lifetime Consumer Warranty

    The warranty does not cover damage to the unit caused by installation or removal of the unit. DEI, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage.
  • Page 3 DEI does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this security system.

  • Page 4: Table Of Contents

    Table of Contents Limited Lifetime Consumer Warranty What Is Included ..........1 Important Information .

  • Page 5: What Is Included

    This owner’s guide should help you to get the most out of your sys- tem. Please take the time to read it thoroughly prior to using the system. You can print extra or replacement copies of this guide from DEI’s website at www.dei.com. 1999 Directed Electronics, Inc. ©...

  • Page 6: Fcc/Id Notice

    Your Warranty Your warranty card must be returned and the bar code serial number must not be removed. If the warranty card is not returned you don’t have a warranty. It is also necessary to keep your proof of purchase which reflects that the product was installed by an authorized deal- er.

  • Page 7: Using Your System

    Using Your System Arming You can activate, or arm, the system by locking the doors with your factory keyless entry transmitter. When the system arms, you will hear a short siren sound, or chirp, and see the parking lights flash once.

  • Page 8: Disarming

    When armed, your vehicle is protected as follows: Light impacts will trigger the warn away signal. When trig- gered, the siren will chirp and the parking lights will flash for a few seconds. Heavy impacts will trigger the system. The triggered sequence is 30 or 60 seconds of constant siren and flashing parking lights.

  • Page 9: Disarming The System Without A Transmitter

    Disarming the System Without a Transmitter This feature allows you to override the system without the trans- mitter should it be lost, damaged or disabled. To do this, you must have the vehicle's ignition key and know where the Valet is located.

  • Page 10: Remote Valet

    To enter or exit Valet ® Mode with the Valet switch: Turn ignition to “on” position, then turn to “off” position. Press and release the Valet switch within 10 seconds. The status LED will light steady if you have entered Valet Mode. To exit Valet Mode, repeat the steps above.

  • Page 11: Panic Mode

    Panic Mode If you are threatened in or near your vehicle, you can attract attention by triggering the system with your transmitter! Just press the lock button on your factory keyless transmitter twice within three seconds to enter Panic Mode. The siren will sound and the parking lights will flash for 30 seconds.

  • Page 12: Diagnostics

    If the bypassed sensor tries to trigger the system while it is being bypassed, the 60-minute bypass period will start over. This ensures that a sensor that is continuously triggering will remain bypassed. Doors are covered differently: If the alarm is triggered by an open door for three full cycles (one-and-one-half minutes), the doors will be bypassed until the trigger ceases.

  • Page 13: Arming Diagnostics

    Arming Diagnostics If the system is armed with an input active (door open, sensor trig- gering, etc.) the unit will chirp once when arming and then one more time a few seconds later. This is called bypass notification. Note: Bypass notification will not occur if chirps have been programmed OFF.

  • Page 14: Table Of Zones

    Ignition trigger If the Warn Away response is triggered, the LED will not report it. Rapid Resume Logic This DEI ® system will store its current state to non-volatile mem- ory. If power is lost and then reconnected the system will recall the stored state from memory.

  • Page 15: Programming Options

    Programming Options Programming options control what your system does during nor- mal operation, and require little or no additional parts. However, some may require additional installation labor. The following is a list of the program settings, with the factory settings in bold: Active arming (only with the transmitter) or passive arming (automatic arming 30-seconds after closing the last door).

  • Page 16: Security & Convenience Expansions

    ger response. In the delayed mode, nothing will happen for 15 seconds once the door is opened. After 15 seconds the unit will trigger the full trigger response. Panic/Auxiliary Channel: This unit has the ability to control an optional accessory, such as power window control. In the default setting pressing the lock button twice will activate Panic Mode.

  • Page 17: Glossary Of Terms

    Power Window Control: Power window control is provided with the 529T or 530T systems. The 529T system will roll up two win- dows automatically when the system is armed, or roll two windows down when you transmit channel 2 or 3, The 530T can roll two windows both up and down.
  • Page 18 Valet ® Switch: A small push button switch mounted somewhere inside the vehicle. It is used to override the alarm when a trans- mitter is lost or damaged, or to put it into Valet ® Mode. Zone: A zone is a separate input that the alarm can recognize as unique.
  • Page 19 Notes 1999 Directed Electronics, Inc. ©...

  • Page 20: Quick Reference Guide (Removable)

    QUICK REFERENCE GUIDE: To arm the system You can arm the system by locking the doors with your factory keyless entry transmitter. When the system arms, your will hear a short chirp, and see the parking lights flash once. To disarm the system To disarm the system, unlock the doors using your factory keyless trans- mitter.
  • Page 21 Call (800) 477-1372 for more information about our products and services. DEI is committed to delivering on time, the best products we know how to provide, and to constantly work with our customers and vendors to improve our products, qual- ity, delivery and customer friendly features.
