I. Specifications
Model
Head
Inclination
Eyepieces
Interpupillary distance
Diopter adjustment
Nosepiece
Objectives
Magnifications
Stage
Stage size
Stage X-Y range
Upper limit stop
Condenser
Focusing
Illumination
Power
SW350B
360° rotatable Binocular Siedentopf
30°
Wide-field 10X and 25X pairs
48-75mm
On left tube, +/-5dp
Quadruple revolving
Achromatic
4X, NA 0.1, working distance 37.5mm
10X, NA 0.25, working distance 7.35mm
40X(Spring), NA 0.65, working distance 0.29mm
100X (Spring, Oil), NA 1.25, working distance 0.18mm
40X, 100X, 250X, 400X, 1000X and 2500X
Double-layered mechanical stage with slide holder
130mmx130mm
70mmx30mm
Rack stop preset but adjustable
NA 1.25 with iris diaphragm
Coaxial coarse and fine focusing system
Built-in 1W LED transmitted illumination with intensity control
110-240V AC adapter (included)
