1 0 : 1 T a s t t e i l e r / P r o b e H Z 2 0 0 mit autom. Teilungsfaktor-Kennung with auto attenuation ID Handbuch / Manual Deutsch / English...
Page 2
10 : 1 Tastteiler HZ200 (mit autom. Teilungsfaktor-Kennung) Technische Daten Teiler-Verhältnis: 10 : 1 Bandbreite: 250 MHz Anstiegszeit: <2,4 ns Eingangsimpedanz: 10 MΩ II 12pF Max. Eingangsspannung (CAT I): 400 V (DC + peak AC) (abnehmend mit zunehmender Frequenz) Niederfrequenzkompensation: Hochfrequenzkompensation: Kabellänge: ca. 1,20 m Handhabung Wechsel der Tastkopfspitze Die Tastkopfspitze herausschrauben und durch die mitgelieferte zweite auf gleiche Weise ersetzen. Tastkopf-Abgleich: Auf kürzestmögliche Masseverbindung achten Abgleich 1 kHz: Tastkopf an 1 kHz-Rechtecksignal anlegen.
Page 3
Lieferumfang 1 Tastkopf 5 IC Isolierkappe 2 Masseleitung 6 Ersatzspitze 3 Klemmhaken 7 Schutzkappe 4 Trimmstift 1 kHz Signal falsch richtig falsch 1 MHz Signal falsch richtig falsch...
Page 4
10 : 1 Probe HZ200 (with auto attenuation ID) Specifications Attenuation ratio: 10 : 1 Bandwidth: 250 MHz Rise time: <2,4 ns Input impedance: 10 MΩ II 12pF Max. Input voltage (CAT I): 400 V (DC + peak AC) (derating with increasing frequency) LF compensation: HF compensation: Cable length: approx. 1.20 m How to use Change of probe tip Unscrew the probe tip and replace with new item supplied.
Page 5
Included in delivery 1 Probe 5 IC Insulating cap 2 Ground lead 6 Probe tip replacement 3 Retractable hook 7 Protection cap 4 Adjustment tool 1 kHz Signal incorrect correct incorrect 1 MHz Signal incorrect correct incorrect...
