Install a DDR2 module in DIMM1/DIMM2.
1. Unlock the DIMM latch.
2. Align the DDR2 module's cutout with the DIMM slot notch.
Slide the DDR2 module into the DIMM slot.
Cutout
Notch
Latch
Latch
3. Check that the latches are closed, and the DDR2 module is firmly installed.
