I N S T A L L A T I O N I N S T R U C T I O N S
SMALL FLAT PANEL STATIC WALL MOUNT
Model: FSR Series
Specifications:
•
Designed for installation on single wood studs or
drywall (1/2" minimum thickness); either option
provides ±1/2" lateral shift.
•
Weight capacity of 45 lbs (20 kg) for wood stud or
drywall installation.
BEFORE YOU BEGIN
WARNING: It is the installer's responsibility to make sure all components are properly assembled and installed using
the instructions provided. Failure to read, thoroughly understand, and follow all instructions can result in serious
personal injury, damage to equipment, or voiding of factory warranty.
•
If you have any questions about this these instructions or your specific installation, contact Chief Manufacturing
at 1-800-582-6480 or 952-894-6280.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE 700
SAVAGE, MINNESOTA 55378 USA
8804-000290
©2006 Chief Manufacturing
www.chiefmfg.com
01/06
Advertisement
Related Manuals for CHIEF FSR Series
Summary of Contents for CHIEF FSR Series
- Page 1 Failure to read, thoroughly understand, and follow all instructions can result in serious personal injury, damage to equipment, or voiding of factory warranty. • If you have any questions about this these instructions or your specific installation, contact Chief Manufacturing at 1-800-582-6480 or 952-894-6280. CHIEF MANUFACTURING INC.
- Page 2 Model: FSR Series IMPORTANT WARNINGS AND CAUTIONS! WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corresponding instructions.
-
Page 3: Tools Required For Installation
Chief Customer Service at 1-800-582-6480. Table 1: Parts Item Description PLATE, Wall ANCHOR, Hollow Wall, #10-24 WASHER, Flat, Standard Machine Screw, #10 SCREW, Phillips Pan Head Sheet Metal, #10 x 2-1/2" (10) Figure 1: Parts Model: FSR Series (20) (30) (40) -
Page 4: Installation
Model: FSR Series INSTALLATION The FSR may be installed on either a single wood stud, or drywall (1/2" minimum thickness). INSTALL MOUNT TO SINGLE WOOD STUD 1. Determine approximate mounting location, keeping in mind the display size. 2. Use a stud sensor to locate applicable wood stud. - Page 5 2. Open latching flag by rotating flag clockwise on plate (10) (See Figure 5). 3. Lift and maneuver display mounting buttons out of button openings. Model: FSR Series Button location for 100mm x 100mm pattern (4 places) Button location for...
- Page 6 Model: FSR Series Installation Instructions...
