8. Reset from Power-up
• Restore mains to the unit after making sure to check all system wiring is
complete, and after you have selected the desired DIP switch settings.
• Press the reset button located beneath the flip down cover on the front of
the unit, all of the characters will briefly appear on the display, followed
by the 12hr clock format screen.
• After 1 minute the screen will time out showing a default time
of 12:00AM.
• There are 3 timed controlled periods per day, and the default
Programmes are as follows;
Heating (HTG)
06:00AM ON
7
08:00AM OFF
10:00AM ON
12:00PM OFF
06:00PM ON
10:00PM OFF
9. Setting the Time and Date
9.1 To alter the time and date at any time, press and hold the Select button
for 3 seconds, the display light will illuminate.
9.2 The default clock format is 12Hr which will be displayed on the screen.
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the TRT036N and is the answer not in the manual?
Questions and answers
have not been able to set time despite following all instructions
To set the time on a Timeguard TRT036N:
1. Press and hold the Select button for 3 seconds to begin setting the clock.
2. The 12-hour symbol will be displayed.
3. Use the arrow buttons to switch between 12-hour and 24-hour formats.
4. Press the Select button to move to setting the hour (the hour will blink).
5. Use the arrow buttons to adjust the hour to your local time.
6. Press the Select button to move to setting the minutes (the minutes will blink).
7. Use the arrow buttons to adjust the minutes.
8. Press the Select button to move to setting the year.
9. Use the arrow buttons to set the correct year.
10. Press the Select button to move to setting the month.
11. Use the arrow buttons to set the correct month.
12. Press the Select button to move to setting the day.
13. Use the arrow buttons to set the correct day.
Once all settings are adjusted, the clock will be set.
