Parts List - Linear Technology DC1736A Demo Manual

DEMO MANUAL DC1736A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C3
4 1 C5
5 1 C6
6 1 D1
7 1 L1
8 1 R1
9 1 R2
10 1 R5
11 1 R6
12 1 U1
Additional Circuits
13 1 C4
14 1 C7
15 0 R7, R8
Hardware—For Demo Board Only
16 7 E1, E2, E3, E4, E5, E6, E7
17 2 JP1, JP2
18 2 Shunt
4
PART DESCRIPTION
Cap., X5R, 47μF 10V 20% 1210
Cap., X5R, 0.47μF 25V 10% 0603
Cap., X5R, 10μF 50V 10%, 1210
Cap., C0G, 10pF 50V 10%, 0402
Cap., X7R, 10nF 25V 10%, 0402
Diode, Scholtky, PowerDi5
IND, 3.3μH
Res., Chip, 1.00M 1/16W 1% 0402
Res., Chip, 576k 1/16W 1% 0402
Res., Chip, 78.7k 1/16W 1% 0402
Res., Chip, 200k 1/16W 1% 0402
I.C., MSE16
Cap., Elect.,100μF 50V 10%
Cap., X5R, 1μF 16V 20% 0603
Res., 0402
Turret, 0.094"
JMP, 1X3-079
Shunt, 2mm Ctrs.
MANUFACTURER/PART NUMBER
TDK, C3225X5R1A476M
TDK, C1608X5R1E474K
TDK, C3225X5R1H106K
TDK, C1005C0G1H100D
TDK, C1005X7R1E103K
DIODE INC, PDS360-13
VISHAY, IHLP2020CZER3R3M01
VISHAY, CRCW04021M00FKED
VISHAY, CRCW0402576KFKED
VISHAY, CRCW040278K7FKED
VISHAY, CRCW0402200KFKED
LINEAR TECH., LT3975EMSE
SUN ELECT, 50CE100BS
AVX, 0603YD105MAT
OPT
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
dc1736af
