INSTALL SHEET

ELECTRICAL PROPERTIES

Panel compatibility
Streaming option
Without streaming option
Power requirements
Battery life
Standard usage (up to 5 videos per month)
High usage (about 30 videos per month)
Standby current consumption
Max current consumption
RADIO PROPERTIES
®
RF S2View technology
Radio type
Operating frequency
• 868MHz - OSMVC 200 (Europe, Africa, Asia)
• 915 MHz - OSMVC 601 (USA, Canada, South America)
• 920 MHz - OSMVC 702 (Australia, South America)
Transmission security
Supervision
Radio antenna

VIDEO PROPERTIES

Camera
Angle
Sensor type
Lighted video
Night vision video
Infrared illumination
Infrared illumination distance
Video
Video format
Framerate
Video resolution
Average video file size
Snapshot
Format
Resolution
Average snapshot file size
OSMVC OUTDOOR STREAMING MOTION VIEWER
W panels
X and VISIO panels
Type C - 4 Lithium batteries 3,6 V LS14500
Spread spectrum bidirectionnal
AES encryption algorithm
Radio, batteries, tamper, position
Integrated
Programmable : Color or B&W
Black & white automatic infrared
Automatic with 4 IR LEDs
Up to 12m
H264 (MPEG if not available)
5 images per second
QVGA (320x240)
VGA (640x480)
DETECTION PROPERTIES
Infrared detection specifications
Technology
Type
Detection lens
Tamper detection
Tilt
4 years
BOX
2 years
130 μA
Physical properties
320 mA
Material
Dimensions
Weight
Environmental data
Operating temperature
Max. relative humidity
Protection marking
Installation / Mounting
Mounting height
Mounting angle
Mounting
90°
CMOS
220 ko
JPEG
8 ko
Passive infrared DSP
Dual element sensor
1 m wide curtain
Position change, shock, wall and cover tamper
Polycarbonate UL94
130,5mm x 102,44mm x 141,5mm
261g (without batteries)
-25°/+70°C
95%, without condensing
IP 65 / IK 06
2.5 m to 3.5 m
Use mounting kit (sold separately)
5° to 10°
