The Texas Instruments LMR33630ARNXEVM and LMR33630CRNXEVM evaluation modules help
designers to evaluate the operation and performance of the LMR33630A and LMR33630C buck
regulators. The LMR33630 is a family of easy-to-use synchronous step-down DC-DC converters capable
of driving up to 3 A of load current from an input voltage of 3.8 V to 36 V. The LMR33630xRNXEVMs
feature a selectable output voltage of 3.3 V or 5 V and a switching frequency of either 400 kHz or 2.1
MHz. See the
LMR33630 data sheet
The EVM options are found in
LMR33630ARNXEVM
LMR33630CRNXEVM
..........................................................................................................................
1
.....................................................................................................................
2
3
.....................................................................................................................
4
5
6
Bill of Materials
1
EVM Board Connections
2
EVM Card Edge Connections
3
EVM Card Edge Connections for EMI Filter
4
Jumper Locations
....................................................................................................................
5
FRA Setup
6
Efficiency: V
IN
7
Efficiency: V
IN
8
LMR33630EVM Schematic
9
10
11
12
13
Trademarks
All trademarks are the property of their respective owners.
SNVU583 - February 2018
Submit Documentation Feedback
LMR33630xRNXEVM User's Guide
for additional features, detailed description, and available options.
Table
1.
Table 1. Device and Package Configurations
EVM
LMR33630ARNX
LMR33630CRNX
........................................................................................................
.................................................................................................................
.............................................................................................................
....................................................................................................
..............................................................................................
............................................................................................................
.....................................................................................
= 12 V, ƒ
= 2.1 MHz
SW
.....................................................................................
= 12 V, ƒ
= 400 kHz
SW
.................................................................................................
............................................................................................................
...................................................................................................
.......................................................................................................
.......................................................................................................
...............................................................................................
Copyright © 2018, Texas Instruments Incorporated
DEVICE
FREQUENCY / Output Current
Contents
List of Figures
.............................................................................
User's Guide
SNVU583 - February 2018
400 kHz / 3A
2100 kHz / 3A
LMR33630xRNXEVM User's Guide
2
6
7
8
9
14
2
3
4
5
6
7
7
8
9
10
11
12
13
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments LMR33630ARNXEVM
Summary of Contents for Texas Instruments LMR33630ARNXEVM
-
Page 1: Table Of Contents
SNVU583 – February 2018 LMR33630xRNXEVM User’s Guide The Texas Instruments LMR33630ARNXEVM and LMR33630CRNXEVM evaluation modules help designers to evaluate the operation and performance of the LMR33630A and LMR33630C buck regulators. The LMR33630 is a family of easy-to-use synchronous step-down DC-DC converters capable of driving up to 3 A of load current from an input voltage of 3.8 V to 36 V. -
Page 2: Setup
• VIS - Input voltage sense connection. • GNDS - Ground sense point for analog measurements. LOAD INPUT SUPPLY Figure 1. EVM Board Connections LMR33630xRNXEVM User’s Guide SNVU583 – February 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... - Page 3 Setup www.ti.com (-) (-) INPUT LOAD SUPPLY TOP FRONT VOUT BOTTOM FRONT Figure 2. EVM Card Edge Connections SNVU583 – February 2018 LMR33630xRNXEVM User’s Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...
- Page 4 VOUT - This jumper is used to select one of the two pre-defined output voltages. The "3.3V" position provides a 3.3-V output; while the "5V" position provides a 5-V output. LMR33630xRNXEVM User’s Guide SNVU583 – February 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...
- Page 5 • A - Connection for frequency response analyzer (on bottom of board) - see Figure SNVU583 – February 2018 LMR33630xRNXEVM User’s Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...
-
Page 6: Operation
EVM should be routed as shown in Figure 3. Note that if a common-mode choke is used, then the input and output grounds are not at the same potential. LMR33630xRNXEVM User’s Guide SNVU583 – February 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 7: Performance Curves
C001 C002 Figure 6. Efficiency: V = 12 V, ƒ = 2.1 MHz Figure 7. Efficiency: V = 12 V, ƒ = 400 kHz SNVU583 – February 2018 LMR33630xRNXEVM User’s Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 8: Schematic
Schematic www.ti.com Schematic Figure 8. LMR33630EVM Schematic LMR33630xRNXEVM User’s Guide SNVU583 – February 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 9: Board Layout
Board Layout www.ti.com Board Layout Figure 9. Top View of EVM SNVU583 – February 2018 LMR33630xRNXEVM User’s Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 10: Evm Top Copper Layer
Board Layout www.ti.com Figure 10. EVM Top Copper Layer LMR33630xRNXEVM User’s Guide SNVU583 – February 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 11: Evm Mid-Layer One
Board Layout www.ti.com Figure 11. EVM Mid-Layer One SNVU583 – February 2018 LMR33630xRNXEVM User’s Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 12: Evm Mid-Layer Two
Board Layout www.ti.com Figure 12. EVM Mid-Layer Two LMR33630xRNXEVM User’s Guide SNVU583 – February 2018 Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... -
Page 13: Evm Bottom Copper Layer
Board Layout www.ti.com Figure 13. EVM Bottom Copper Layer SNVU583 – February 2018 LMR33630xRNXEVM User’s Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated... - Page 14 Bill of Materials www.ti.com Bill of Materials Table 2. BOM for LMR33630ARNXEVM DESIGNATOR DESCRIPTION MANUFACTURER PART NUMBER QUANTITY C1, C17 CAP, CERM, 0.1 µF, 25 V, +/- 10%, X7R, 0603 06033C104KAT2A C2, C3, C4, C5 CAP, CERM, 22 µF, 25 V, +/- 10%, X5R, 1210...
- Page 15 RES, 0, 5%, 0.25 W, AEC-Q200 Grade 0, 1206 Vishay-Dale RCA12060000ZSEA Ferrite Bead, 600 ohm @ 100 MHz, 4 A, 2220 Laird-Signal HI2220P601R-10 Integrity Products SNVU583 – February 2018 LMR33630xRNXEVM User’s Guide Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated...
