- Page 1 E4/E5 Manual 1.4 en...
- Page 2 General information E4/E5 Manual Version: 1.4 en, 03/2016, D2616.EN .01 Copyright © 2016 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference.
-
Page 3: Table Of Contents
2.1 Product description..............5 2.2 Connections................5 2.3 Operation..................6 2.3.1 Controller settings..............6 2.4 Dispersion characteristics............7 2.5 Technical specifications.............. 8 Manufacturer's Declarations........10 3.1 EU conformity of loudspeakers (CE symbol)......10 3.2 WEEE Declaration (Disposal)..........10 d&b E4/E5 Manual 1.4 en... -
Page 4: Safety Precautions
Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b E4/E5 Manual 1.4 en... -
Page 5: E4/E5 Loudspeaker
Under no circumstances should the safety hook [S] be used to support other loads. The E4 and E5 rear panels incorporate a M10 threaded insert to accept the Z5356 E4/E5 Ball joint adapter. In addition, a safety hook [S] is integrated in the rear panel to allow the attachment of a secondary safety wire. -
Page 6: Operation
Positive CPL values create an adjustable low frequency boost (0 to +5 dB) and can be set when the system is used in full range mode without subwoofers. Fig. 4: Frequency response correction of the CPL circuit d&b E4/E5 Manual 1.4 en... -
Page 7: Dispersion Characteristics
(isobars) at –6 dB and –12 dB. Fig. 5: Isobar diagram horizontal Fig. 6: Isobar diagram vertical Fig. 7: Isobar diagram horizontal Fig. 8: Isobar diagram vertical d&b E4/E5 Manual 1.4 en... -
Page 8: Technical Specifications
D6/10D 114 dB with D80/D20/D12/30D 115 dB (SPLmax peak, pink noise test signal with crest factor 4) Fig. 9: E4 frequency response, standard and CUT modes. E4 loudspeaker Nominal impedance 16 ohms Power handling capacity (RMS/peak 10 ms) 60/400 W Nominal dispersion angle (hor. - Page 9 1 x two pole push terminal (PT - up to 6 mm /AWG 10) Pin assignments NL4 M: 1+/1– Push terminal: Red: (+) / Black: (–) Weight 2.7 kg (6.0 lb) Fig. 12: E5 cabinet dimensions in mm [inch] d&b E4/E5 Manual 1.4 en...
-
Page 10: Manufacturer's Declarations
Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. WEEE-Reg.-Nr. DE: 13421928 d&b E4/E5 Manual 1.4 en... - Page 11 www.dbaudio.com...
