  • Page 1 E18-SUB Manual (3.1 EN)

  • Page 2: Table Of Contents

    Symbols on the equipment Please refer to the information in the operating manual. WARNING! Dangerous voltage! Contents Safety precautions...............3 Information regarding use of loudspeakers..........3 E18-SUB ................4 Connections......................4 Operation with D6 or D12................5 Operation with E-PAC..................5 Operation with P1200A..................5 Technical specifications..................6 Manufacturer's declarations..........7 EU conformity of loudspeakers (CE symbol)..........7...

  • Page 3: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. E18-SUB Manual (3.1 EN) Safety precautions - 1...

  • Page 4: E18-Sub

    Connections The E18-SUB cabinet is fitted with a pair of EP5 connectors. All pins of n.c. both connectors are wired in parallel. The E18-SUB uses the pin assignments 3/4 and 5 (Pin 5: SenseDrive - D12 only and in conjunction with 5-wire cables).

  • Page 5: Operation With D6 Or D12

    Within the D12 amplifier this is available in "Dual Channel" and "Mix TOP/SUB" mode. Up to a total of two E18-SUB loudspeakers can be driven by each D6 or D12 amplifier channel. In applications with low continuous levels and low ambient temperatures up to three cabinets can be connected to a D12 channel.

  • Page 6: Technical Specifications

    E18-SUB subwoofer Nominal impedance....................8 ohms Power handling capacity (RMS / peak 10 ms)........200 /800 W Components......................18" driver Fig. 5: E18-SUB frequency response, Connections........................2 x EP5 standard and 160 Hz settings Pin assignments............3/4 and 5 (Pin 5: SenseDrive - D12) optional........................2 x NL4 Pin assignments......................2+ / 2–...

  • Page 7: Manufacturer's Declarations

    Manufacturer's declarations EU conformity of loudspeakers (CE symbol) This declaration applies to: d&b E18-SUB, Z2253 manufactured by d&b audiotechnik GmbH. All production versions of this type are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications.
  • Page 8 d&b audiotechnik GmbH, Eugen-Adolff-Str. 134, D-71522 Backnang, Germany, Phone +49-7191-9669-0, Fax +49-7191-95 00 00...
