- Page 1 Manual 1.1 en...
- Page 2 General information E6 Manual Version: 1.1 en, 09/2017, D2606.EN .01 Copyright © 2017 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this manual to the new owner.
-
Page 3: Table Of Contents
2.3. Operation................6 2.3.1. Controller settings..............6 2.3.2. Operation with E-PAC............7 2.4. Dispersion characteristics............7 2.5. Technical specifications............9 Manufacturer's Declarations........10 3.1. EU conformity of loudspeakers (CE symbol)....... 10 3.2. WEEE Declaration (Disposal)..........10 d&b E6 Manual 1.1 en... -
Page 4: Safety Precautions
Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b E6 Manual 1.1 en... -
Page 5: E6 Loudspeaker
Z5377 E6 Swivel bracket, Z5378 E6 Horizontal bracket or a safety wire. The connector panel of the E6 cabinet is recessed and tilted to allow deployment as a stage monitor. With the panel on the right hand side, the cabinet is oriented correctly. -
Page 6: Operation
Positive CPL values create an adjustable low frequency boost (0 to +5 dB) and can be set when the system is used in full range mode without subwoofers. Frequency response correction of the CPL function d&b E6 Manual 1.1 en... -
Page 7: Operation With E-Pac
2.3.2. Operation with E-PAC Selecting E6 mode enables the E-PAC to drive up to three E6 loudspeakers. LO IMP mode configures the E-PAC to drive a maximum of five E6 loudspeakers with a 6 dB reduction in input level to the loudspeakers. - Page 8 3. Take the horn at its outer edges and turn it until it snaps into the desired direction. 4. Relocate and fix the front grill. Þ Make sure the safety wire slips into the recess between baffle and cabinet body. d&b E6 Manual 1.1 en...
-
Page 9: Technical Specifications
120 dB with D12/D20/30D 123 dB with D80 123 dB (SPLmax peak, pink noise test signal with crest factor 4) E6 frequency response, standard and CUT modes E6 loudspeaker Nominal impedance 20 ohms Power handling capacity (RMS/peak 10 ms) 150/800 W Nominal dispersion angle (hor. -
Page 10: Manufacturer's Declarations
Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b E6 Manual 1.1 en... - Page 12 www.dbaudio.com...
