2) Product Description and Applications
2.1 Applications
PL600H/PL1000H is applied for residential automation of sliding gates. PL600H/PL1000H has to be operated with
electricity and it's forbidden to be operated by back-up batteries for normal use. Back-up batteries (optional) are only
allowed for emergent operation when there is a power failure, and the gearmotor can be released by the key to move
the gate manually.

2.2 Description of the Automation

The following diagram of PL600H/PL1000H typical installation describes some terms live in whereever you are and
whenever you are and accessories of a gate automation system:
G F

2.3 Description of Devices

PL600H/PL1000H may include the accessories shown in Figure 2.
Please check the accessories the same as the package provided.
Attention: Some accessories of PL600H/PL1000H are not included due to local regulations or customized order.
A) 1 PL600H/PL1000H electromechanically gearmotor
including control unit
B) 2 release keys
C) 1 pair of PH-2 photocells
D) 2 PR-1 radio transmitters
E) 1 PF- flashing light
F) 1 PKS-1 key selector with two keys
G) 1 PPB-1 push button
H) 2 limit switch brackets
I) Various small parts: screws, nuts, etc. (see table1)
J) 4 PRK-1 Rack
K) Green Box
Table 1: List of small parts for PL600H & PL1000H
Bent bins / Washers / Nut
Foundation Plate
Screws with no head
Limit Switch
C
I
H
2 pcs / 6 pcs / 4 pcs
1 pce
4 pcs
2 sets
Figure 1
A
F G
I
C E
A
Figure 2
B C
D
H
J
INSTRUCTIONS PL600H/PL1000H
H
E
K
