www.wackergroup.com
OPERATOR'S MANUAL
0
1
5
4
5
8
2
E
N
0154582en
0602
Vibroplate
WP 1550A
WP 1550AW
001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WP 1550A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wacker Neuson WP 1550A

Summary of Contents for Wacker Neuson WP 1550A

  • Page 1 0154582en 0602 Vibroplate WP 1550A WP 1550AW OPERATOR’S MANUAL...
  • Page 2 BELGIE 1730 ASSE-MOLLEM ASSESTEENWEG 17 Tel. (32) 02-4528509+07 4040 Herstal 4 Avenue 9800 Deinze Kortrijkse Steenweg 400 Tel. (09)-386 8529 B - 6041 Gosselies Rue Adrienne Bolland s/n Tel. 071-372450 ÇESKÁ REPUBLIKA 19402 PRAHA 9-HLOUBETIN KOLBENOVA 259 Tel. (0042) 2 862165 DANMARK 2690 KARLSLUNDE RØRGANGEN 6...

  • Page 3: Table Of Contents

    WP 1550A/AW Table of Contents Foreword Safety Information Laws Pertaining to Spark Arresters ............4 Operating Safety .................. 5 Operator Safety while using Internal Combustion Engines ....6 Service Safety ..................7 Label Locations ..................8 Warning and Informational Labels ............9 Operating Labels ................
  • Page 4 Table of Contents WP 1550A/AW Maintenance Periodic Maintenance Schedule ............20 Cleaning Plate ..................20 Drive Belt .....................21 Exciter Lubrication ................22 Spark Plug ...................23 Engine Oil ....................24 Air Cleaner ..................25 Cleaning Sediment Cup ..............26 Carburetor Adjustment - Honda ............27 5.10 Troubleshooting ...................28 5.11...
  • Page 5 Foreword Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. WARNING Foreword This manual provides information and procedures to safely operate and maintain this Wacker model.

  • Page 6: Safety Information

    Safety Information WP 1550A/AW Safety Information This manual contains DANGER, WARNING, CAUTION, and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 7: Operating Safety

    WP 1550A/AW Safety Information Operating Safety Familiarity and proper training are required for the safe operation of equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read the operating instructions contained in both WARNING this manual and the engine manual and familiarize yourself with the location and proper use of all controls.

  • Page 8: Operator Safety While Using Internal Combustion Engines

    Safety Information WP 1550A/AW Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling! Read and follow warning instructions in engine owner's manual and safety guidelines below. Failure to follow warnings and DANGER safety guidelines could result in severe injury or death.

  • Page 9: Service Safety

    WP 1550A/AW Safety Information Service Safety Poorly maintained equipment can become a safety hazard! In order for the equipment to operate safely and properly over a long period of time, periodic maintenance and occasional repairs are necessary. WARNING 2.4.1 DO NOT attempt to clean or service machine while it is running.

  • Page 10: Label Locations

    Safety Information WP 1550A/AW Label Locations WARNING WARNUNG ADVERTENCIA 10 W 30 AVERTISSEMENT wc_si000015gb.fm...

  • Page 11: Warning And Informational Labels

    WP 1550A/AW Safety Information Warning and Informational Labels Wacker machines use international pictorial labels where needed. These labels are described below: Label Meaning To prevent hearing loss, wear hearing protec- tion when operating this machine. Read the operator's manual for machine infor- mation.
  • Page 12 Safety Information WP 1550A/AW Label Meaning WARNING! Hand injury if caught in moving belt. Always replace belt guard. CAUTION! Read and understand the supplied operator's manual before operating this machine. Failure to do so increases the risk of injury to yourself or others.
  • Page 13 WP 1550A/AW Safety Information Label Meaning This machine may be covered by one or more patents. wc_si000015gb.fm...

  • Page 14: Operating Labels

    Safety Information WP 1550A/AW Operating Labels Wacker machines use international pictorial labels where needed. These labels are described below: Label Meaning Open fuel flow valve. Push or turn engine switch to ON position. Close choke. Place throttle in the IDLE position.
  • Page 15 WP 1550A/AW Safety Information Label Meaning Push or turn engine switch to OFF position. Open choke. Place throttle in the FAST position. Throttle control lever: Turtle = Idle or Slow Rabbit = Full or Fast wc_si000015gb.fm...

  • Page 16: Technical Data

    Technical Data WP 1550A/AW Technical Data Engine Data - Honda WP 1550A/AW 0007576 0007579 Engine Engine Make Honda Engine Model GX 160 K1 QX2 Rated Power kW (Hp) 4.1 (5.5) Spark Plug type NGK BPR 6ES Electrode Gap mm (in.) 0.7 –...

  • Page 17: Plate Data

    WP 1550A/AW Technical Data Plate Data WP 1550A/AW 0007576 0007579 Plate Operating Weight kg (lbs.) 86 (190) Water Tank Capacity l (qts.) 10.4 (11.0) Exciter Speed rpm / belt 5800 Exciter Lubrication ml (oz.) 150 (5) Automatic Transmission Fluid Dextron III / Mercon or equivalent Sound and Vibration Specifications The required sound specifications, per Appendix 1, Paragraph 1.7.4.f...

  • Page 18: Dimensions

    Technical Data WP 1550A/AW Dimensions mm (in.) 9 6 5 ( 3 8 ) 6 8 6 ( 2 7 ) 5 0 8 ( 2 0 ) g r 0 0 0 0 8 1 wc_td000007gb.fm...

  • Page 19: Operation

    WP 1550A/AW Operation Operation Recommended Fuel The engine requires regular grade unleaded gasoline. Use only fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system. Consult engine owner’s manual for complete fuel specifications. Before Starting 4.2.1 Read and understand safety and operating instructions at beginning of this manual.

  • Page 20: To Stop

    Operation WP 1550A/AW To Stop See Graphic: wc_gr000014 4.4.1 Reduce engine RPM to idle by moving throttle completely to right (d2). 4.4.2 Turn engine switch to “OFF” (e2). 4.4.3 Close fuel valve by moving lever to the left (a2). Application This plate is designed for compacting loose, granular soils, gravel, and paving stones.

  • Page 21: Operation

    WP 1550A/AW Operation Operation See Graphic: wc_gr000076 Run engine at full throttle and allow plate to pull itself along at its normal speed. When operating on an incline it may be necessary to assist plate by pushing it forward slightly. Depending on the material being compacted, three or four passes are recommended to achieve the best compaction.

  • Page 22: Maintenance

    Maintenance WP 1550A/AW Maintenance Periodic Maintenance Schedule The chart below lists basic engine maintenance. Refer to engine manufacturer’s Operation Manual for additional information on engine maintenance. Daily After Every Every Every before first 2 weeks month year starting 20 hrs.

  • Page 23: Drive Belt

    WP 1550A/AW Maintenance Drive Belt See Graphic: wc_gr000077 On new machines or after installing a new belt, check belt tension after first 20 hours of operation. Check and adjust belt every 50 hours thereafter. To change the belt: 5.3.1 Remove the beltguard and remove the four hex nuts (a) holding pulley halves (b) together.

  • Page 24: Exciter Lubrication

    Maintenance WP 1550A/AW Exciter Lubrication See Graphic: wc_gr000078 The exciter assembly is a self-contained, sealed unit. The bearings are lubricated using automatic transmission fluid (see Technical Data for type). Change fluid once every year or 300 hours of operation. When changing fluid, replace O-ring (a).

  • Page 25: Spark Plug

    WP 1550A/AW Maintenance Spark Plug See Graphic: wc_gr000028 Clean or replace spark plug as needed to ensure proper operation. Refer to the engine Owner’s Manual. The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Do not touch the muffler while it is hot.

  • Page 26: Engine Oil

    Maintenance WP 1550A/AW Engine Oil See Graphic: wc_gr000022 5.6.1 Drain oil while the engine is still warm. 5.6.2 Remove the oil fill plug (a) and drain plug (b) to drain oil. Note: In the interests of environmental protection, place a plastic sheet and a container under the machine to collect any liquid which drains off.

  • Page 27: Air Cleaner

    WP 1550A/AW Maintenance Air Cleaner See Graphic: wc_gr000025 The engine is equipped with a dual element air cleaner. Service air cleaner frequently to prevent carburetor malfunction. CAUTION: NEVER run engine without air cleaner. Severe engine damage will occur. NEVER use gasoline or other types of low flash point solvents for cleaning the air cleaner.

  • Page 28: Cleaning Sediment Cup

    Maintenance WP 1550A/AW Cleaning Sediment Cup See Graphic: wc_gr000029 5.8.1 Turn fuel valve off. 5.8.2 Remove sediment cup (a) and O-ring (b). 5.8.3 Wash both thoroughly in a nonflammable solvent. Dry and reinstall them. 5.8.4 Turn fuel valve on and check for leaks.

  • Page 29: Carburetor Adjustment - Honda

    WP 1550A/AW Maintenance Carburetor Adjustment - Honda See Graphic: wc_gr000032 5.9.1 Start the engine and allow it to warm up to operating temperature. 5.9.2 Set the pilot screw (a) 2 turns out. See Note. 5.9.3 With the engine idling, turn the pilot screw (a) in or out to the setting that produces the highest rpm.

  • Page 30: Troubleshooting

    Maintenance WP 1550A/AW 5.10 Troubleshooting Problem / Symptom Reason / Remedy Plate does not develop full • Engine throttle control not completely open. speed. Poor compaction. • Throttle control not adjusted correctly. • Ground too wet, plate sticking. Allow soil to dry before compacting.

  • Page 31: Lifting Machine

    WP 1550A/AW Maintenance 5.12 Lifting Machine See Graphic: wc_gr000079 See Technical Data for the weight of the machine. To lift machine manually: 5.12.1 Stop the engine. 5.12.2 Obtain help from a partner and plan the lift. 5.12.3 Grasp the machine by its cage (a) and lifting handle (b).

  • Page 32: Transporting Machine

    Maintenance WP 1550A/AW 5.13 Transporting Machine See Graphic: wc_gr000277 To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. WARNING 5.13.1 Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling.
  • Page 33 Plancha Vibradora Patin Vibrant WP 1550AW 2. Type - Typ - Tipo - Type WP 1550A 3. Item number of equipment / Gerätetypnummer / Número de referencia de la máquina / Numéro de référence du matériel : 0007576, 0007579 4. Net installed power / absolute installierte Leistung / 4,1 kW Potencia instalada neta / Puissance installée nette:...
