Operator's Manual
Vibroplate
WP 1030A
0402342en
001
0110
0
4
0
2
3
4
2
E
N

Advertisement

Table of Contents
loading

Related Manuals for Wacker Neuson WP 1030A

Summary of Contents for Wacker Neuson WP 1030A

  • Page 1 Operator’s Manual Vibroplate WP 1030A 0402342en 0110...
  • Page 2 This publication may be photocopied by the original purchaser of the machine. Any other type of reproduction is prohibited without express written permission from Wacker Neuson Corporation. Any type of reproduction or distribution not authorized by Wacker Neuson Corporation represents an infringement of valid copyrights. Violators will be prosecuted. Trademarks All trademarks referenced in this manual are the property of their respective owners.

  • Page 3: Table Of Contents

    WP 1030A Table of Contents Foreword Safety Information Laws Pertaining to Spark Arresters ............5 Operating Safety .................. 6 Operator Safety while using Internal Combustion Engines ....7 Service Safety ..................8 Label Locations ..................9 Warning and Informational Labels ............10 Technical Data Engine Data ..................
  • Page 4 Table of Contents WP 1030A Maintenance Periodic Maintenance Schedule ............19 Spark Plug ...................21 Air Cleaner ..................22 Engine Oil ....................23 Adjusting Engine Speed ..............23 Carburetor Adjustment ................24 Cleaning Sediment Cup ..............24 Protection frame ..................25 Exciter Lubrication ................26 4.10 Cleaning the Plate ................26 4.11...
  • Page 5 Foreword This manual provides information and procedures to safely operate and maintain this Wacker Neuson model. For your own safety and protection from injury, carefully read, understand and observe the safety instructions described in this manual. Keep this manual or a copy of it with the machine. If you lose this manual or need an additional copy, please contact Wacker Neuson Corporation.

  • Page 6: Safety Information

    Safety Information WP 1030A Safety Information This manual contains DANGER, WARNING, CAUTION, NOTICE, and NOTE signal words which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 7: Laws Pertaining To Spark Arresters

    WP 1030A Safety Information Laws Pertaining to Spark Arresters Notice: State Health Safety Codes and Public Resources Codes specify that in certain locations spark arresters be used on internal combustion engines that use hydrocarbon fuels. A spark arrester is a device designed to prevent accidental discharge of sparks or flames from the engine exhaust.

  • Page 8: Operating Safety

    These areas get hot and may cause burns. 1.2.3 Do not use accessories or attachments that are not recommended by Wacker Neuson. Damage to equipment and injury to the user may result. 1.2.4 NEVER operate the machine with the beltguard missing. Exposed drive belt and pulleys create potentially dangerous hazards that can cause serious injuries.

  • Page 9: Operator Safety While Using Internal Combustion Engines

    WP 1030A Safety Information Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. Failure to follow the WARNING warnings and safety standards could result in severe injury or death.

  • Page 10: Service Safety

    A hot muffler could ignite the debris and start a fire. 1.4.6 Replace worn or damaged components with spare parts designed and recommended by Wacker Neuson Corporation. 1.4.7 Disconnect the spark plug on machines equipped with gasoline engines, before servicing, to avoid accidental start-up.

  • Page 11: Label Locations

    WP 1030A Safety Information Label Locations wpmgr007317 wpm_si000443gb.fm...

  • Page 12: Warning And Informational Labels

    Safety Information WP 1030A Warning and Informational Labels Wacker Neuson machines use international pictorial labels where needed. These labels are described below: Label Meaning WARNING! To prevent hearing loss, wear hearing protec- tion when operating the machine. WARNING! Hot surface! Guaranteed sound power level in dB(A).
  • Page 13 WP 1030A Safety Information Label Meaning Lifting point (manual). DANGER! Engines emit carbon monoxide; operate only in well-ventilated area. Read the Operator’s Manual. No sparks, flames, or burning objects near the machine. Shut off the engine before refueling. Label-machine model...
  • Page 14 Safety Information WP 1030A Label Meaning Throttle control lever: Turtle = Idle or Slow Rabbit = Full or Fast wpm_si000443gb.fm...

  • Page 15: Technical Data

    WP 1030A Technical Data Technical Data Engine Data Engine Power Rating Net power rating per SAE J1349. Actual power output may vary due to conditions of specific use. WP 1030A 0630015 Engine Engine Make Honda Engine Model GX100U SE3 Max. rated power @ rated kW (Hp) 2.1 (2.8) @ 3600 rpm...

  • Page 16: Machine Data

    Technical Data WP 1030A Machine Data WP 1030A 0630015 Plate Weight 50 ( 110 ) kg (lbs.) Exciter Speed 5800 ± 100 Exciter Lubrication 116 ( 4 ) ml (oz.) Automatic Transmission Fluid Dextron III / Mercon or equivalent Dimensions 300 (11.81) x 1023 (40.28) x 629 (24.76)

  • Page 17: Dimensions

    WP 1030A Technical Data Dimensions mm (in.) 629 (24.76) 1023(40.28) 300(11.81) wpmgr007302 wpm_td000381gb.fm...

  • Page 18: Operation

    Operation WP 1030A Operation Recommended Fuel The engine requires regular grade unleaded gasoline. Use only fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system. Consult engine owner’s manual for complete fuel specifications. Application This plate is designed for compacting loose granular soils, gravel, and paving stones.

  • Page 19: To Start

    WP 1030A Operation To Start See Graphic: wc_gr000014 3.4.1 Open fuel valve by moving lever to the right (a1). Note: If engine is cold, move choke lever to close position (b1). If engine is hot, set choke to open position (b2).

  • Page 20: Operation

    Operation WP 1030A Operation Run the engine at full throttle and allow the plate to pull itself along at its normal speed. When operating on an incline it may be necessary to assist the plate by pushing it forward slightly. When operating downhill hold the plate back slightly, if it begins to pick up speed.

  • Page 21: Maintenance

    WP 1030A Maintenance Maintenance Periodic Maintenance Schedule 4.1.1 Engine Maintenance The chart below lists basic engine maintenance. Refer to the engine manufacturer’s Operation Manual for additional information. Daily After Every Every Every before first 2 weeks month year starting 20 hrs.
  • Page 22 Maintenance WP 1030A 4.1.2 Machine Maintenance The chart below lists basic machine maintenance. Daily After Every Every Every before first 2 weeks month year starting 20 hrs. 50 hrs. 100 hrs. 300 hrs. Check external hardware. Check and adjust drive belt.

  • Page 23: Spark Plug

    WP 1030A Maintenance Spark Plug See Graphic: wc_gr000028 Clean or replace the spark plug as needed to ensure proper operation. Refer to your engine operator’s manual. The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Do not touch the muffler while it is hot.

  • Page 24: Air Cleaner

    Maintenance WP 1030A Air Cleaner See Graphic: wc_gr000025 The engine is equipped with a dual element air cleaner. Service air cleaner frequently to prevent carburetor malfunction. NOTICE: NEVER run engine without air cleaner. Severe engine damage will occur. NEVER use gasoline or other types of low flash point solvents for cleaning the air cleaner.

  • Page 25: Engine Oil

    WP 1030A Maintenance Engine Oil See Graphic: wc_gr000022 4.4.1 Drain the oil while the engine is still warm. 4.4.2 Remove the oil filler plug (a) and the drain plug (b) to drain the oil. Note: In the interests of environmental protection, place a plastic sheet and a container under the machine to collect any liquid that drains off.

  • Page 26: Carburetor Adjustment

    Maintenance WP 1030A Carburetor Adjustment See Graphic: wc_gr000032 4.6.1 Start the engine and allow it to warm up to operating temperature. 4.6.2 Set the pilot screw (a) two turns out. See Note. 4.6.3 With the engine idling, turn the pilot screw (a) in or out to the setting that produces the highest rpm.

  • Page 27: Protection Frame

    WP 1030A Maintenance Protection frame See Graphic: wpmgr007305 Heavy-duty frame design wrapped around the upper mass provides full protection on the engine and water tank. The frame features a central lifting point for easy on/off loading and placement of the plate into confined areas.

  • Page 28: Exciter Lubrication

    Maintenance WP 1030A Exciter Lubrication See Graphic: wpmgr007139 The bearings in the exciter assembly are splash lubricated and rotate at very high speed. It is important to maintain the exciter oil at the correct level and change it regularly. Check oil level in exciter every 50 hours of operation.

  • Page 29: Lifting Machine

    WP 1030A Maintenance 4.11 Lifting Machine See Graphic: wpmgr007304 See Technical Data for weight of machine. To lift machine manually: 4.11.1 Stop the engine. 4.11.2 Obtain help from a partner and plan the lift. To avoid burns or fire hazards, let the engine cool before transporting the machine or storing it indoors.

  • Page 30: Transporting Machine

    Maintenance WP 1030A 4.12 Transporting Machine See Graphic: wpmgr007306 To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. WARNING 4.12.1 Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling.

  • Page 31: Troubleshooting

    WP 1030A Maintenance 4.14 Troubleshooting Problem / Symptom Reason / Remedy Plate does not develop full • Engine throttle control not completely open. speed. Poor compaction. • Throttle control not adjusted correctly. • Ground too wet, plate sticking. Allow soil to dry before compacting.
  • Page 33 EC DECLARATION OF CONFORMITY WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES AUTHORIZED REPRESENTATIVE IN THE EUROPEAN UNION Axel Häret WACKER NEUSON SE Preußenstraße 41 80809 München hereby certifies that the construction equipment specified hereunder: Category: Vibratory Plates Machine function: This plate is designed for compacting loose, granular soils, gravel, and paving stones. It is intended to be used in confined areas and areas next to structures such as walls, curbs, and foundations.
  • Page 35 CE-KONFORMITÄTSERKLÄRUNG WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES BEVOLLMÄCHTIGTER VERTRETER FÜR DIE EUROPÄISCHE Axel Häret GEMEINSCHAFT WACKER NEUSON SE Preußenstraße 41 80809 München bescheinigt, daß das Baugerät: Art: Rüttelplatten Maschinenfunktion: Diese Platte eignet sich zum Verdichten von losen und körnigen Böden, Kies und Verbundsteinen, ebenso in engen Bereichen an Gebäuden, Randsteinen und Fundamenten.
  • Page 37 DECLARACIÓN DE CONFORMIDAD DE LA CE WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES REPRESENTANTE AUTORIZADO EN LA UNIÓN EUROPEA Axel Häret WACKER NEUSON SE Preußenstraße 41 80809 München certifica que la máquina de construcción: Categoría: Planchas Vibratorias Función de la máquina: Esta placa está...
  • Page 39 DÉCLARATION DE CONFORMITÉ C.E. WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES REPRÉSENTANT AGRÉÉ AUPRÈS DE L’UNION Axel Häret EUROPÉENNE WACKER NEUSON SE Preußenstraße 41 80809 München atteste que le matériel : Catégorie: Plaques Vibrantes Fonction de la machine : Cette plaque est conçue pour le compactage de la terre lâche et granuleuse, du gravier et des pavés. Elle est destinée à...
  • Page 40 Fax: +49 - (0)89-3 54 02-3 90 Wacker Neuson Corporation · P.O. Box 9007 · Menomonee Falls, WI 53052-9007 · Tel. : (262) 255-0500 · Fax: (262) 255-0550 · Tel. : (800) 770-0957 Wacker Asia Pacific Operations · Skyline Tower, Suite 2303, 23/F · 39 Wang Kwong Road, Kowloon Bay, Hong Kong · Tel. +852 2406 60 32 · Fax: +852 2406 60 21...
