SERVICE MANUAL
HANDSFREE STAINLESS STEEL TELEPHONE
WITH AUTOMATIC DIAL FEATURE
EQUIPPED WITH SPK1.07 FIRMWARE
Communication Equipment
& Engineering Company
FOR
MODEL SSP-561-D
(OPTIONAL ADA FEATURE)
SSP-561-D-ADA-SPK1.07-ISSUE 4.0
Serving the Telephone Industry Since 1930
519 W South Park Street
Okeechobee, FL 34972
Voice: 863-357-0798
Fax: 863-357-0006
Advertisement
Table of Contents
Related Manuals for CEECO SSP-561-D
Summary of Contents for CEECO SSP-561-D
- Page 1 SSP-561-D-ADA-SPK1.07-ISSUE 4.0 SERVICE MANUAL MODEL SSP-561-D HANDSFREE STAINLESS STEEL TELEPHONE WITH AUTOMATIC DIAL FEATURE EQUIPPED WITH SPK1.07 FIRMWARE (OPTIONAL ADA FEATURE) Serving the Telephone Industry Since 1930 Communication Equipment 519 W South Park Street & Engineering Company Okeechobee, FL 34972...
- Page 2 Issue 4.0 IMPORTANT INFORMATION CUSTOMER Please fill in before you continue. The following information is necessary when calling CEECO for assistance. MODEL NUMBER MODEL SSP-561-D W/SPK1.07 FIRMWARE SERIAL NUMBER DATE MANUFACTURED LOCATION INSTALLED For us to better serve you, please have this information available when calling for technical support.
-
Page 3: Table Of Contents
5.0 RECOMMENDED TOOLS AND TEST EQUIPMENT ........7 7.0 TESTING........................9 8.0 SPECIFICATIONS....................9 9.0 PARTS LIST ......................10 10.0 FCC NOTICE......................11 11.0 REPAIR AND RETURN INFORMATION............12 12.0 WARRANTY POLICY ..................13 13.0 DIAGRAM....................... 14 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 4: Introduction
GENERAL The CEECO hands free telephone is a sturdy, vandal resistant, stainless steel speakerphone with an optional ADA feature. Instead of a hookswitch and handset, the telephone has a press to start/press to stop button for the initiation and termination of phone calls. Manual volume control is also provided inside the telephone on the PC board. -
Page 5: Programming
Enter #00 to enter the telephone options location. By entering a selected number of 0-9 for each of the ten digits represented on the following page, the phone is customized for the particular installation. Enter the ten (10) selected digits now. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 6: Programming Continued
• Be sure to log your entries below for future reference. (OPTION TABLE) #00 0 _ _ 0 0 _ 0 _ 0 _ 1 2 3 4 5 6 7 8 9 10 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 7: Programming Continued
“CALL & HANGUP” button to hang up the phone. The call will be terminated and the LED will go out. NOTE: If the telephone is being used to make emergency calls, CEECO cannot assume responsibility for the called party’s response. - Page 8 C. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. D. Use caution when installing or modifying telephone lines. CEECO Communication Equipment & Engineering Company PROPRIETARY...
-
Page 9: Testing
10.25” wide x 13.125” high x 2.625” deep (SSP) (handset on hook). Mounting: Vertical surface mount. Weight: Approximately 8 lbs. UL listed no.: 60F5 FCC registration: BW8USA-73021-MT-E Ringer equivalence: 0.4a Type jack: RJ11C CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 10: Parts List
PART NUMBER DESCRIPTION 406-019 Outer cover security screw 301-018 Modular line cord 301-054-UL Modular Connector (RJ11C) 700-008 Keypad Cable 660-000 CEECO SPK PC board 705-110 Connectorized Keypad 6020 Momentary Panel Switch 14024 Speaker 14067 Microphone 391-002 Stainless Steel Panel 361-01... -
Page 11: Fcc Notice
FCC registration number and ringer equivalence number. These numbers are listed in section 9.0. The FCC further requires that you notify your local telephone company when permanently disconnecting this telephone. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 12: Repair And Return Information
11.3 NON-WARRANTY REPAIR CEECO will repair equipment out of warranty for a set charge plus parts. The customer must pay the shipping costs both directions. 11.4 RETURN FOR CREDIT Material may be returned for credit only with prior approval. Material authorized for return is subject to a 20% restocking charge based on the manufacturer’s list price. -
Page 13: Warranty Policy
This warranty is limited to the value of material only. CEECO will repair or replace any unit during this period if found to be defective for reasons other than abuse and improper use or improper installation. -
Page 14: Diagram
ON position BEFORE going off-hook. When programming is completed, move the mini jumpers to the OFF position. NOTE: Do not leave the mini jumpers in the ON position; this will decrease battery life. CEECO Communication Equipment & Engineering Company PROPRIETARY...
