WPP(HOB)-531-F OR SSP-511-F-SPKSPD1.00-ISSUE4.0
SERVICE MANUAL
FOR
MODEL WPP(HOB)-531-F
HANDS FREE WEATHERPROOF TELEPHONE
AND
MODEL SSP-511-F
STAINLESS STEEL PANEL TELEPHONE
EQUIPPED WITH
SPKSPD1.00 SPEED DIAL
FIRMWARE
Serving the Telephone Industry Since 1930
Communication Equipment
519 West South Park Street
& Engineering Company
Okeechobee, Florida 34972
Voice: 863-357-0798
Fax: 863-357-0006
Advertisement
Table of Contents
Related Manuals for CEECO SSP-511-F
Summary of Contents for CEECO SSP-511-F
- Page 1 WPP(HOB)-531-F OR SSP-511-F-SPKSPD1.00-ISSUE4.0 SERVICE MANUAL MODEL WPP(HOB)-531-F HANDS FREE WEATHERPROOF TELEPHONE MODEL SSP-511-F STAINLESS STEEL PANEL TELEPHONE EQUIPPED WITH SPKSPD1.00 SPEED DIAL FIRMWARE Serving the Telephone Industry Since 1930 Communication Equipment 519 West South Park Street & Engineering Company Okeechobee, Florida 34972...
-
Page 2: Important Information
ISSUE 4.0 IMPORTANT INFORMATION CUSTOMER Please fill in before you continue. The following information is necessary when calling CEECO for assistance. MODEL WPP(HOB)-531-F OR SSP-511-F MODEL NUMBER EQUIPPED WITH SPKSPD1.00 FIRMWARE SERIAL NUMBER DATE MANUFACTURED LOCATION INSTALLED For us to better serve you, please have this information available when calling for technical support. -
Page 3: Table Of Contents
7.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS ....12 8.0 OVER-VOLTAGE PROTECTION DIAGRAM ............13 9.0 TESTING ..............................13 10.0 SPECIFICATIONS .........................14 11.0 PARTS LIST ............................15 13.0 REPAIR AND RETURN INFORMATION ..............17 14.0 WARRANTY POLICY ........................18 15.0 DIAGRAM .............................19 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 4: Introduction
Signage or a director is suggested near the telephone for user instruction. The SSP-511-F Stainless Steel Panel Telephone may also be purchased in a full weatherproof housing, WPP-531-F, or open-faced weather-resistant housing, HOB-531-F. In all cases the panel telephone remains the same. -
Page 5: Programming
Enter #00, followed by a series of ten (10) digits as selected from the following page. Location “00” is the telephone options location. By entering a selected number of 0-9 into each of the ten digit locations, the phone is customized for the particular installation. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 6: Programming Continued
Do Not Dial PBX number in Location #91 Dial PBX number in Location #91 Digit 9: Always 0 for this model. Digit 10: No Wink Detect Length of the Wink (l = 50ms incremental to 450ms. 5 is recommended) CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 7: Programming Continued
Enter #3018005551212 in the programming sequence. When in normal operating mode, the user dials 30 and the phone will Speed Dial - 1-800-555-1212. Be sure to log your entries in the speed dial table on the next page for future reference. CEECO Communication Equipment & Engineering Company PROPRIETARY... - Page 8 #39 _ - _ _ _ - _ _ _ - _ _ _ _ #20 _ - _ _ _ - _ _ _ - _ _ _ _ #40 _ - _ _ _ - _ _ _ - _ _ _ _ CEECO Communication Equipment & Engineering Company PROPRIETARY...
- Page 9 #79 _ - _ _ _ - _ _ _ - _ _ _ _ #60 _ - _ _ _ - _ _ _ - _ _ _ _ #80 _ - _ _ _ - _ _ _ - _ _ _ _ CEECO Communication Equipment & Engineering Company PROPRIETARY...
- Page 10 "CALL & HANGUP” button. Return the two plastic mini-jumpers to the "OFF" or outermost position, as depicted in the diagram on the last page of this manual. The phone is now ready for use. CEECO Communication Equipment & Engineering Company PROPRIETARY...
-
Page 11: Operation
It would be necessary to contact the manufacturer of the PBX. RECOMMENDED TOOLS AND TEST EQUIPMENT DTMF Test Set Volt/Ohm Meter 3/8" Nut Driver 5/16" Nut Driver Flat Blade Screw Driver Security Tool, CEECO Part Number 301-064 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 12: Installation Notes And Assembly Instructions
Separate the cover assembly from the Housing. Run the inside station wire through the Housing and terminate on to the RJ11C modular jack on the housing, as depicted on the following page. This CEECO- provided modular jack must be used, as it contains required over-voltage protection. -
Page 13: Over-Voltage Protection Diagram
Reaction: The called party answers. A normal speakerphone conversation is allowed. Action: Finish the conversation. Press the "CALL" button, or wait until time-out occurs (if programmed as such). Reaction: The call is terminated. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 14: Specifications
MOUNTING: 4 holes spaced 8”H x 5 7/8”W and 5/16” Dia. WEIGHT: Approximately 5 lb MEMORY RETENTION: Non-volatile memory retention FCC REGISTRATION: BW88T7-13823-TE-T RINGER EQUIVALENCE: 0.7A TYPE JACK: RJ11C UL LISTED NO.: 6OF5 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 15: Parts List
ISSUE 4.0 11.0 PARTS LIST QUANTITY PART NUMBER DESCRIPTION 705-110 Keypad 700-008 Keypad Cable 660-000 CEECO SPK Board 6020 Momentary Panel Switch 14123 Speaker 301-006 Ringer 301-009 Network 331-010 Stainless Steel Panel 331-005 Cast Aluminum Weather Proof Housing 331-HOB-B Black 0pen style weather-resistant housing... -
Page 16: Fcc Notice
FCC registration number and ringer equivalence number. These numbers are listed in Section 11.00. The FCC further requires that you notify your local telephone company when permanently disconnecting this telephone. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 17: Repair And Return Information
Okeechobee, Florida 34972 (863) 357-0798 13.3 NON-WARRANTY REPAIR CEECO will repair equipment out of warranty for a set charge plus parts. The customer must pay the shipping costs both directions. 13.4 RETURN FOR CREDIT Material may be returned for credit only with prior approval. Material authorized for return is subject to a 20% restocking charge based on the manufacturer’s list... -
Page 18: Warranty Policy
Printed circuit boards should not be repaired in the field. If a unit is found to be faulty, replace it with another unit and return the faulty unit to CEECO for repair. Modifications by any one other than CEECO will void the warranty. -
Page 19: Diagram
ON position BEFORE going off-hook. When programming is completed, move the mini jumpers to the OFF position. NOTE: Do not leave the mini jumpers in the ON position, this will decrease battery life. CEECO Communication Equipment & Engineering Company PROPRIETARY...
