Crestron TPS-WPK Operation Manual

Water Resistant Cover Kit for

Isys TPS-2000L: TPS-WPK
The Crestron water resistant cover kit for the Isys
urethane cover for a mounted panel. There are four covers per kit. When properly installed
the cover prevents liquids and other air-born materials from settling directly onto the panel,
but does not interfere with regular usage of the unit.
No tools are required to install the TPS-WPK cover; a silicone adhesive is provided. The
panel must be properly setup (i.e., cleaned and connected to the network) as outlined in the
latest revision of the TPS-2000L Operations Guide prior to installing the cover. Complete the
steps listed adjacent to the diagram for installation.
MOUNTING
SURFACE
WARNING: Silicone adhesive is an irritant to skin, eyes, and respiratory tract. Skin and eye protection
required. Avoid repeated or prolonged contact. Good ventilation is required.
WARNING: To avoid shock hazard and possible damage to the unit, never install a touchpanel where it
may be exposed to rain or very high humidity. This kit is designed to resist water (eg. protect unit from
wet hands) and in no way provides waterproof protection.
Further Inquiries
If you cannot locate specific information or have questions after reviewing this sheet, please
take advantage of Crestron's award winning customer service team by calling the
corporate headquarters at 1-888-CRESTRON [1-888-273-7876]. For assistance in your local time zone,
refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices.
You can also log onto the online help section of the Crestron
questions about Crestron products. First-time users will need to establish a user account to fully benefit
from all available features.
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576

TPS-2000L touchpanel provides a
INSTALLED
TPS-2000L
TOUCHPANEL
LOCATION
TPS-WPK COVER
Water Resistant Cover Kit for Isys
Specifications subject to change without notice.
1. Remove the backing from
the tape that surrounds
the perimeter of the
cover.
2. Place the cover over the
panel making sure that
the gap in the tape
perimeter is located at
the bottom.
3. Firmly press down the
cover so that it
completely encloses the
touchpanel.
4. Except for the gap at the
bottom, apply a bead of
GAP silicone rubber adhesive
around the outer edge of
the cover (form a seal
with the mounting
surface).
5. Do not use the touch-
panel while the adhesive
cures (typically 24 hours).
Crestron
website (www.crestron.com) to ask

TPS-2000L: TPS-WPK
www.crestron.com
DOC. 5993
02.02
