Summary of Contents for Crestron MMK-2000L
- Page 1 Crestron MMK-2000L & WMKM-2000L Mud Mount Kits Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2002 Crestron Electronics, Inc.
-
Page 3: Supplied Hardware
The MMK-2000L consists of three items with differing quantities. These items produce an assembly that attaches to the PMK-2000L or BB-2000L. The WMKM-2000L consists of the same three items that make up the MMK-2000L as well as one mounting plate. The mounting plate is the item that provides the necessary support for post-construction applications. -
Page 4: Installation
MMK-2000L Procedure The procedure in this section provides the necessary steps for the assembly of the MMK-2000L to either the PMK-2000L or BB-2000L. It is assumed that the PMK-2000L or BB-2000L has been secured to the stud according to the procedures in the latest revisions of their respective Installation Guides (Doc. - Page 5 STANDARD DRYWALL SCREW (NOT SUPPLIED) QUANTITY 4 6. When the mud ring plate is in position, bend the top two flanges of the ring upward (approximately 90 degrees) and the bottom two flanges downward (approximately 90 degrees). 7. Use four standard drywall screws (of adequate length) to secure the mud ring plate to the rest of the assembly.
- Page 6 Mud Mount Kits NOTE: Do not over tighten screws. Doing so may over-dimple or rip the mud ring plate. WMKM-2000L Procedure The procedure in this section provides the necessary steps for the assembly and installation of the WMKM-2000L into a wall. Complete the steps in the order provided.
- Page 7 6. Use the drywall saw or equivalent to produce a level, rectangular cutout in the drywall that measures 6 high (11.389 cm). 7. Insert the symmetrical mud ring plate into the opening, as shown in the illustration after this step. OPENING IN DRYWALL 8.
- Page 8 NOTE: Fastener/mounting plate assembly will have slight play; this is normal. It allows for minor adjustments to the TPS-2000L during installation. Bend Flanges APPROXIMATELY 90° 6 • Mud Mount Kits: MMK-2000L & WMKM-2000L Crestron MMK-2000L & WMKM-2000L INSERTED MUD RING PLATE 9.
- Page 9 15. When dry, the TPS-2000L can be installed using the four tapped holes in the mounting plate. Refer to the latest revision of the TPS-2000L Operations Guide (Doc. 5972) for details. Mud Mount Kits: MMK-2000L & WMKM-2000L • 7 Mud Mount Kits...
-
Page 10: Further Inquiries
For assistance in your local time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 11: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6025 15 Volvo Drive Rockleigh, NJ 07647 02.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
