- Page 1 Crestron MMK-V12 & WMKM-V12 Mud Mount Kits Installation Guide...
-
Page 2: Industry Compliance
1-888-CRESTRON Industry Compliance As of the date of manufacture, the MMK-V12 and WMKM-V12 have been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. All brand names, product names and trademarks are the property of their respective owners. -
Page 3: Table Of Contents
Crestron MMK-V12 & WMKM-V12 Mud Mount Kits Contents Mud Mount Kits: MMK-V12 & WMKM-V12 Description..........................1 Setup ............................5 Supplied Hardware ...................... 5 Installation ........................5 Resources..........................14 Reference Documents....................14 Further Inquiries ......................14 Future Updates ......................14 Return and Warranty Policies ....................15 Merchandise Returns / Repair Service .............. -
Page 5: Mud Mount Kits: Mmk-V12 & Wmkm-V12
For concrete and rock mounting material, allow for proper ventilation before mounting the touchpanel. There are two Mud Mount Kits. The MMK-V12 mud ring is an optional accessory for the BB-V12 back box and PMK-V12 pre-construction mounting kit. Pre-construction refers to framed walls prior to hanging drywall. It is designed to compensate for drywall cutout imperfections, providing a grated surface suitable for the application of drywall compound for a finished appearance. - Page 6 Mud Mount Kits Crestron MMK-V12 & WMKM-V12 The dimensions of the MMK-V12 and WMKM-V12 are shown below. Overall Dimensions (Mud Ring Plate) 13.63 in 0.05 in (347 mm) 12.17 in (2 mm) (309 mm) 0.50 in (13 mm) 12.06 in (307 mm) 10.57 in...
- Page 7 Overall Dimensions (Mounting Plate) 13.63 in (347 mm) 11.30 in (287 mm) 5.65 in (144 mm) 0.06 in (2 mm) 11.99 in (305 mm) 10.80 in (275 mm) Mud Mount Kits: MMK-V12 & WMKM-V12 • 3 Installation Guide – DOC. 6892A...
- Page 8 (313 mm max) 5/8 in (16 mm) 3/16 in (5 mm) Ø 1/4 in (6.5 mm) TYP. 11 1/8 in max (282 mm max) 6 1/8 in (157 mm) 4 • Mud Mount Kits: MMK-V12 & WMKM-V12 Installation Guide – DOC. 6892A...
-
Page 9: Setup
The MMK-V12 consists of three parts. These parts produce an assembly that attaches to the BB-V12 or PMK-V12. The WMKM-V12 consists of six parts, three of which make up the MMK-V12, as well as a mounting plate, cutout template and mounting screws. - Page 10 Mud Mount Kits Crestron MMK-V12 & WMKM-V12 NOTE: The MMK-V12 has been optimized for mounting in 5/8” (15 mm) drywall. You may use 1/2” – 1” (12.5 – 25 mm) without issue. Thinner or thicker drywall will cause issues with the installation.
- Page 11 Insert and Secure Mud Ring Plate into PMK-V12 (or BB-V12) Stud Flange PMK-V12 (not included) Drywall Mud Ring (2025263) Drywall Screws (not included) Screw length should not exceed drywall thickness by more than 1/2" (13 mm). Mud Mount Kits: MMK-V12 & WMKM-V12 • 7 Installation Guide – DOC. 6892A...
- Page 12 PMK-V12 (or BB-V12). Refer to the latest version of the V12-WALL and WMKC-V12 Installation Guide (Doc. 6893) for installation instructions. Refer also to the comprehensive illustration shown on page 9. 8 • Mud Mount Kits: MMK-V12 & WMKM-V12 Installation Guide – DOC. 6892A...
- Page 13 The only tools or materials required and not supplied are a saw or equivalent, a level, four application appropriate screws, a #2 Phillips screwdriver and tools/material to apply drywall joint compound. Mud Mount Kits: MMK-V12 & WMKM-V12 • 9 Installation Guide – DOC. 6892A...
- Page 14 1. Insert the two pins on one adjustment plate into the top two outer holes on the mounting plate, as shown in the illustration below. Create the Adjustment/Mounting Plate Assembly Mounting Plate (2024536) Push-on Fastener (4) (2004121) Adjustment Plate (2) (2004825) 10 • Mud Mount Kits: MMK-V12 & WMKM-V12 Installation Guide – DOC. 6892A...
- Page 15 Insert Mud Ring Plate into Opening Mounting Surface Mud Ring (2025263) NOTE: Screw length should not exceed mounting surface thickness by more than 1/2" (13 mm). Holes for Screws (4) (not included) Mud Mount Kits: MMK-V12 & WMKM-V12 • 11 Installation Guide – DOC. 6892A...
- Page 16 11. Verify that the plate is level before tightening. NOTE: Do not overtighten screws. Doing so may damage the plate. 12 • Mud Mount Kits: MMK-V12 & WMKM-V12 Installation Guide – DOC. 6892A...
- Page 17 Push-on Fastener (4) (2024121) Adjustment Plate (2) (2004825) Mounting Plate (2) (2024536) Mounting Surface Mud Ring (2025263) V12-WALL (not included) Screw (6) #06-32 x 1 1/2" (2007254) Bezel Mud Mount Kits: MMK-V12 & WMKM-V12 • 13 Installation Guide – DOC. 6892A...
-
Page 18: Resources
Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. You can also log onto the online help section of the Crestron website (www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 19: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures. - Page 20 Crestron Electronics, Inc. Installation Guide – DOC. 6892A 15 Volvo Drive Rockleigh, NJ 07647 (2025425) Tel: 888.CRESTRON 11.09 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
