- Page 1 Crestron MK-IM-RX Pole Mount Kit for iMedia Receivers Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2006 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron MK-IM-RX Contents Pole Mount Kit for iMedia Receivers: MK-IM-RX Introduction ... 1 Features and Functions ... 1 Physical Description... 1 Assembly to the iMedia Receiver ... 3 Problem Solving ... 9 Further Inquiries ... 9 Future Updates ... 9 Return and Warranty Policies ... -
Page 5: Pole Mount Kit For Imedia Receivers: Mk-Im-Rx
Supplied Components Physical Description The MK-IM-RX is a steel mounting kit that allows iMedia receivers to be attached to a pole that holds a projector. The kit can attach to the top or side of the receiver as shown in the following diagrams. - Page 6 Pole Mount Kit for iMedia Receivers Top-Mounted iMedia Receiver Side-Mounted iMedia Receiver 2 • Pole Mount Kit for iMedia Receivers: MK-IM-RX Crestron MK-IM-RX Installation Guide – DOC. 6451...
-
Page 7: Assembly To The Imedia Receiver
Crestron MK-IM-RX Assembly to the iMedia Receiver The MK-IM-RX can be assembled and mounted to either the top or the side of an iMedia receiver. Choose the appropriate mounting style for your application. Required Tools #1 Phillips screwdriver ¼” Allen wrench Top Mount NOTE: When installing, observe all local safety codes. - Page 8 Pole Mount Kit for iMedia Receivers 4 • Pole Mount Kit for iMedia Receivers: MK-IM-RX 2. Attach the bottom bracket of the MK-IM-RX to the iMedia receiver’s mounting holes using the four #6-32 screws and spacers provided. The mounting holes have PEM nuts to hold the screws.
- Page 9 Crestron MK-IM-RX Pole Mount Kit for iMedia Receivers 4. Connect iMedia transmitters and display devices to the mounted iMedia receiver. Top-Mounted iMedia Receiver Pole Mount Kit for iMedia Receivers: MK-IM-RX • 5 Installation Guide – DOC. 6451...
- Page 10 NOTE: When installing, observe all local safety codes. The MK-IM-RX attaches to the iMedia receiver in a side-mount application with the included mounting plate. To mount the MK-IM-RX to the side of an iMedia receiver, perform the following: 6 • Pole Mount Kit for iMedia Receivers: MK-IM-RX 1.
- Page 11 Locating the PEM Nuts NUTS MUST BE ON THE SIDE FACING THE IM-RX UNIT 3. Attach the bottom bracket of the MK-IM-RX to the attached mounting plate using the four #6-32 screws and spacers provided. Attaching Bottom Bracket to Mounting Plate...
- Page 12 Pole Mount Kit for iMedia Receivers 8 • Pole Mount Kit for iMedia Receivers: MK-IM-RX 4. Secure the assembly to the customer-supplied pole with the top bracket and the two ¼”-20 screws and washers provided. Securing Assembly to Pole TOP BRACKET NOTE: An Allen wrench is required to tighten the ¼”-20 screws.
-
Page 13: Problem Solving
For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 14: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 15 Crestron MK-IM-RX Pole Mount Kit for iMedia Receivers This page intentionally left blank. Pole Mount Kit for iMedia Receivers: MK-IM-RX • 11 Installation Guide – DOC. 6451...
