CLOUDLINE
MIXED FLOW INLINE FAN SYSTEMS
USER MANUAL
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for AC Infinity CLOUDLINE

Summary of Contents for AC Infinity CLOUDLINE

  • Page 1 CLOUDLINE MIXED FLOW INLINE FAN SYSTEMS USER MANUAL USER MANUAL...
  • Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
  • Page 4 MANUAL CODE CL2109X2 PRODUCT MODEL UPC-A CLOUDLINE S4 AI-CLS4 819137020290 CLOUDLINE S6 AI-CLS6 819137020306 CLOUDLINE S8 AI-CLS8 819137020849 CLOUDLINE S10 AI-CLS10 819137020856 CLOUDLINE S12 AI-CLS12 819137021006 CLOUDLINE T4 AI-CLT4 854759004785 CLOUDLINE T6 AI-CLT6 854759004792 CLOUDLINE T8 AI-CLT8 819137020276 CLOUDLINE T10...

  • Page 5: Manual Index

    ................. Page 26 Other Settings ................Page 40 Download the App ................. Page 41 Add a Device ................. Page 42 Programming................Page 44 Settings................... Page 54 ....................Page 55 Other AC Infinity Products ............. Page 57 Warranty ..................Page 58...

  • Page 6: Key Features

    KEY FEATURES QUIET PWM MOTOR STATOR BLADE FANS SMART CONTROLLER PWM-controlled motor features Hydro-mechanical stator Features automation controls precise speed control, reduced blades enable efficient airflow that activate the fan according rotor noise, and energy-efficient delivery in high static pressure to temperature, humidity, EC voltage.

  • Page 7: Product Contents

    PRODUCT CONTENTS CLOUDLINE S-Series SPEED MACHINE SCREWS WOOD SCREWS (WALL MOUNT) (WALL MOUNT) CONTROLLER (x1) (x2) (x2) CLOUDLINE T-Series SMART SENSOR MACHINE SCREWS WOOD SCREWS WOOD SCREWS CONTROLLER PROBE (WALL MOUNT) (WALL MOUNT) (WALL HANG) (x1) (x1) (x2) (x2) (x2)
  • Page 8 PRODUCT CONTENTS...

  • Page 9: Installation

    INSTALLATION MOUNTING STEP 1 Unscrew and loosen the metal rings using a Phillips screwdriver and pliers. STEP 2 Remove the motor box from the flange bracket. Remove the wind circle between the motor box and the intake flange.
  • Page 10 INSTALLATION MOUNTING STEP 3 Use the flange bracket to set your desired fan position. Mark the four mounting holes. STEP 4 Drill four holes into the marked locations. Make sure your mounting area is structurally sound and free from obstruction.
  • Page 11 INSTALLATION MOUNTING STEP 5 If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes. You may need to use a hammer to secure them through the holes. STEP 6 Align the flange bracket’s holes with the wall anchors.
  • Page 12 INSTALLATION MOUNTING STEP 7 Place the wind circle back into the intake flange and reposition the metal clamps over the flanges if applicable. STEP 8 Slide the motor box back into the flange bracket, making sure its airflow arrow is pointing in the same direction as the flange bracket’s arrow.
  • Page 13 INSTALLATION MOUNTING STEP 9 Place the metal rings back onto the flanges and tighten the screws back to secure the fan. STEP 10 If installing ducting, use the included duct clamps to secure it to either end of the duct fan, making sure there is a tight seal.
  • Page 14 INSTALLATION HANGING - ROPE CLIPS STEP 11(a) - Hanging Upward If installing with rope hangers (sold separately), loop the ropes around the flanges and tighten the rope to secure the fan. STEP 11(b) - Hanging Downward Loop the two rope hangers around a pole and the fan's bracket.

  • Page 15: Hanging - Straps

    INSTALLATION HANGING - STRAPS STEP 1 Loop the strap around the bracket and a pole. STEP 2 Slip the strap through the inner ladder lock slot from the bottom.
  • Page 16 INSTALLATION HANGING - STRAPS STEP 3 Route the strap into the outer ladder lock slot from the top. Adjust the length of the completed loop as needed. STEP 4 Tuck the loose end through the center gap of the ladder lock to secure the loop.
  • Page 17 INSTALLATION HANGING - STRAPS STEP 5(a) - Hanging Downward Let the fan hang by the pole once the straps are secure. Make sure the fan's airflow arrow is pointing towards your desired direction. STEP 5(b) - Hanging Upward To hang the fan right-side up, loop and tighten the straps, as shown in steps 1-4, around the pole.
  • Page 18 INSTALLATION MOTOR CAP STEP 1 Unscrew the motor cap using a screwdriver. STEP 2 Rotate the motor cap to your desired orientation. Reapply the screws. Rotating the motor cap will not void your warranty.

  • Page 19: Configuration Setup

    INSTALLATION CONFIGURATION SET-UP Intake and Exhaust This fan can be used as either an intake fan or an exhaust fan in grow rooms and larger grow tents. To achieve optimal whole space ventilation, the intake fan or opening - if not using a fan - must be situated at a bottom corner of your grow space.
  • Page 20 POWERING AND SETUP S-SERIES STEP 1 Plug the duct fan’s 4-pin molex connector into the speed controller’s port at the top. STEP 2 Plug the fan's power cord into a wall outlet. The controller will receive power from the fan to operate.
  • Page 21 POWERING AND SETUP T-SERIES STEP 1 You may cable manage the cords using tie mounts, wood screws, and zip ties included with this fan. Secure the tie mounts onto a surface using the wood screws. Loop the zip ties around the cords into the tie mounts.
  • Page 22 POWERING AND SETUP T-SERIES STEP 3 Plug the sensor probe into the controller’s 3.5mm jack. Set the probe near your plants in your grow tent for the most accurate reading. Keep the probe cord away from your HID* grow light ballast's power cord to ensure the controller properly detects climate conditions.
  • Page 23 ADDING MORE FANS The smart controller for the CLOUDLINE T-Series has an additional port so that you can add an S-Series fan to power and control two fans together. Please see below for limitations. T-SERIES CONTROLLER Smart controllers for T-Series models with EC motors can support two fans of any size. The two EC-motor fans must be plugged in to an outlet to power the fans and the controller.
  • Page 24 CLEANING STEP 1 Remove the motor box from the mounting flange. Refer to steps 1-2 on page 9 to learn how to remove the motor box. STEP 2 Use a damp cloth to clear the impeller and fan blades of any dust and debris. Remove the wind circle in between the motor box and input flange.
  • Page 25 CLEANING STEP 3 Clear the stator blades of any dust and debris on the opposite end. Clean the area inside the output and exhaust flanges. STEP 4 Secure the motor box onto the mounting flanges. Refer to steps 7-9 on page 12-13 to learn how to secure the motor box.
  • Page 26 PROGRAMMING FAN SPEED ADJUSTING The controller features a single button that controls the fan speed from 0-8. Pressing the speed button increases the fan speed in one unit increments. Pressing the button at the 8 setting will set the fan speed back to 0. Fan Spee d Indicato r POWERING ON/OFF...

  • Page 27: Controller Mode

    PROGRAMMING 1. MODE BUTTON 2. UP/DOWN BUTTONS 3. SETTING BUTTON Cycles through the controller’s Adjusts the value of your current Cycles through the controller’s available modes: OFF, ON, AUTO mode. The up button increases and available settings: DISPLAY, °F/ °C, (4 triggers), TIMER TO ON, TIMER down button decreases the setting.

  • Page 28: Controller Modes

    PROGRAMMING CONTROLLER MODES Pressing the mode button will cycle through the controller’s available programming modes: OFF, ON, AUTO (4 triggers), TIMER TO ON, TIMER TO OFF, CYCLE (On and Off), and SCHEDULE (On and Off). OFF MODE Your fan will not run while in this mode. The fan speed set while in this mode establishes the minimum speed in other modes.
  • Page 29 PROGRAMMING AUTO MODE (LOW TEMPERATURE TRIGGER) Pressing the up or down button sets the low temperature trigger. The fans will activate if the probe’s reading meets or falls below this threshold. Once triggered, the fan will gradually ramp up to the speed set in ON mode.
  • Page 30 PROGRAMMING AUTO MODE (LOW HUMIDITY TRIGGER) Pressing the up or down button sets the low humidity trigger. The fans will activate if the probe’s reading meets or falls below this threshold. Once triggered, the fan will gradually ramp up to the speed set in ON mode.
  • Page 31 PROGRAMMING TIMER TO OFF MODE Pressing the up or down button sets a countdown time. The fans will run at the speed set in ON Mode until the countdown ends. If there is a speed set in OFF Mode, the fans will run at that speed after the end of the countdown.
  • Page 32 PROGRAMMING SCHEDULE MODE (ON AND OFF) Sets an on clock-time and an off clock-time schedule for the fan to follow daily. Press the up or down button to first set up an on clock-time to trigger ON mode, then press the mode button to set an off clock-time to trigger OFF mode.

  • Page 33: Controller Settings

    PROGRAMMING CONTROLLER SETTINGS Pressing the setting button will cycle through the controller’s available settings: DISPLAY, °F/ °C, CLOCK, CALIB. T°, CALIB. H%, TRANS. T°, and TRANS. H%. DISPLAY SETTING Adjusts the display brightness and auto-dimming. Press the up or down button to cycle through levels 1, 2, 3, A2 and A3;...

  • Page 34: Clock Setting

    PROGRAMMING °F/°C SETTING Changes the displayed units to Fahrenheit or Celsius. Press the up or down button to cycle through F and C. All displayed units will automatically convert when adjusting this setting. CLOCK SETTING Adjusts the current clock time. Press the up or down button to increase or decrease the time.
  • Page 35 PROGRAMMING CALIBRATION TEMPERATURE SETTING Adjusts the temperature reading the sensor probe is measuring. Press the up or down button to increase or decrease the data figure in 2°F (or 1°C) increments. The calibration cycle ranges from -8°F to 8°F (or -4°C to 4°C) and will be applied to the sensor probe’s measurements.
  • Page 36 PROGRAMMING TRANSITION TEMPERATURE SETTING Adjusts the transition threshold between the fan speeds in the AUTO Mode temperature triggers. Press the up or down button to cycle through 0°F to 8°F (0°C to 4°C) and set a transition threshold. The fan speed will be set one level above the OFF Mode speed when the sensor temperature first meets or exceeds the high temperature trigger.
  • Page 37 PROGRAMMING TRANSITION HUMIDITY SETTING Adjusts the transition threshold between the fan speeds in the AUTO Mode humidity triggers. Press the up or down button to cycle through 0% to 8% to set a transition threshold. The fan speed will be set one level above the OFF Mode speed when the sensor humidity first meets or exceeds the high humidity trigger.
  • Page 38 PROGRAMMING ALERT ICONS The alert icons are displayed at the top of the screen. Icons may flash when the controller signals an alert to notify you of any triggered function or alarm. ADVANCE PROGRAMMING Displays when an advance program set in the app is active. "ADV." will appear and override the controller if an automation program is in use.
  • Page 39 PROGRAMMING LOW HUMIDITY ALARM Flashes and beeps with an alert if the humidity falls below the trigger point set in the app. Continues to flash until the humidity rises above the trigger point. TIMER ALERT Flashes when a countdown has completed for TIMER TO ON, TIMER TO OFF, CYCLE, or SCHEDULE Mode.

  • Page 40: Other Settings

    OTHER SETTINGS FACTORY RESET Holding the mode, up, and down buttons together for 5 sec- HOLD + onds will reset your controller and restore factory settings. This clears all user parameters in each controller mode and setting. CONTROLLER LOCK Holding the setting button will lock the controller in your cur- rent mode.

  • Page 41: Download The App

    DOWNLOAD THE APP THE AC INFINITY APP The AC Infinity app enables you to connect with the next generation of our intelligent controllers, giving you access to advance programs and environmental data. Download the AC Infinity app from the App Open the AC Infinity app.

  • Page 42: Add A Device

    ADD A DEVICE Connect the fan and probe into your controller. Launch the app. Tap the (+) button, then Plug the fan into a wall outlet. "SMART CONTROLLERS", and select CONTROLLER 67 to begin pairing. Please note: Bluetooth must be enabled on your mobile device before starting the pairing process.
  • Page 43 ADD A DEVICE Tap DONE button to complete the pairing Your controller will appear in your smart device process. with a unique ID. A-A000A DONE Please note: When pairing the app around multiple controllers, move your mobile device closer to your desired controller.
  • Page 44 APP PROGRAMMING 1. MODE BUTTON 2. TEMPERATURE/HUMIDITY 3. SETTINGS Dropdown displays all available Toggles between current tempera- Adjusts app settings including Device controller modes: OFF, ON, AUTO, ture and humidity readings. Name, Temperature Display, Device TIMER TO ON, TIMER TO OFF, Brightness, Fan Speed Transitions, CYCLE, and SCHEDULE.

  • Page 45: Controls Tab

    APP PROGRAMMING CONTROLS TAB Contains all controller modes including the OFF, ON, AUTO, TIMER TO ON, TIMER TO OFF, CYCLE and SCHEDULE modes. Tap the paired device to enter the Controls tab, Tap the menu button to access the controller where you can adjust the controller modes.
  • Page 46 APP PROGRAMMING CONTROLS TAB The control wheel displays the temperature/humidity, current settings, and time. Use the wheel hands, (+/-) stepper, or sliders Use the toggle switch to activate or deactivate to set your parameters. any climate triggers.
  • Page 47 APP PROGRAMMING ADVANCE PROGRAMMING Creates automated activations, alarms, and push notifications. The adjustable modes in each program include those listed in controls tab. Once an advance program completes its programming (i.e. scheduling), the app will no longer override the controller's onboard settings.
  • Page 48 APP PROGRAMMING ADVANCE PROGRAMMING - AUTOMATION Each automation can support one mode at a time. To automate multiple modes, you must create additional programs, except for TIMER TO ON and TIMER TO OFF in auto- mation. The app will override the controller while an automation is active. Tap the (+) button to create an automation program.
  • Page 49 APP PROGRAMMING ADVANCE PROGRAMMING - ALARMS Alarms will tell your controller to beep whenever your fan switches on or off as a result of the mode(s) you select in the program. Choose between AUTO, TIMER TO ON, TIMER TO OFF, CYCLE and SCHEDULE modes. Alarm programming will also have a climate points setting in which the alarm will go off when temperature and humidity hits a high or low point.
  • Page 50 APP PROGRAMMING ADVANCE PROGRAMMING - NOTIFICATIONS Notification programs will send push notifications to your mobile device whenever your fan switches on or off as a result of the mode(s) you select in the program. Choose between AUTO, TIMER TO ON, TIMER TO OFF, CYCLE and SCHEDULE modes. Notification programming will also have a climate points setting in which you receive push notifications when temperature and humidity hits a high or low point.
  • Page 51 APP PROGRAMMING DATA TAB Logs and stores all temperature and humidity information. Readings are displayed in fluctuation charts and bar graphs and can be viewed in hours, days, weeks, months, and years. Data can be exported as a spreadsheet and sent to other devices by tapping EXPORT CSV DATA.
  • Page 52 APP PROGRAMMING DATA TAB The fluctuation charts and bar graphs allow you to see trends in temperature and humidity and enable you to make the necessary adjustments to your space. Tap on any point in the charts and graphs to see detailed information on the picket. Bar Graphs - This readout displays how often a detected temperature or humidity point occurs over a given timespan.

  • Page 53: History Log

    APP PROGRAMMING HISTORY LOG Logs all advance programming notifications and controller activity. Entries can be filtered by controller functions and programming including triggers, timers, cycles, schedules, automation, alarms, and notifications. Swipe up and down to scroll through the history Tap "SHOW FILTERS" to reveal activity options. log.

  • Page 54: App Settings

    APP SETTINGS SETTINGS Tap the gear icon to access the settings. Sets all controller-related parameters including Device Name, Temperature Display, Screen Brightness, Transitions, and Calibrations. Tap CONFIRM to save your settings. Tapping CANCEL will leave the settings menu without saving changes. Tapping DELETE DEVICE will unpair your controller from the app.
  • Page 55 Yes. You will need to remove the plastic cap so the probe can accurately read climate conditions. Can I mount this inline duct fan vertically? Yes. The CLOUDLINE can be mounted in any orientation, including vertically. Will I be able to hardwire this fan to my own controller or thermostat? We do not recommend hardwiring or splicing our fan's power wires.
  • Page 56 Should I use this inline duct fan as an intake or an exhaust fan? The CLOUDLINE is primarily used as an exhaust fan, but can be used as an intake fan as well. You may use this fan as an intake fan if you need fresh air into your space.
  • Page 57 150 lb. weight capacity. Includes a mounting plate to install your AC Infinity controller onto. Carbon Filters The duct carbon filter is designed to eliminate odors and chemicals for grow tents and hydroponic spaces.

  • Page 58: Warranty

    WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues.
  • Page 59 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
