AC Infinity CLOUDRAY Series User Manual

Whole house fan system
Hide thumbs Also See for CLOUDRAY Series:

Advertisement

Table of Contents

CLOUDRAY
WHOLE HOUSE FAN SYSTEM
USER MANUAL
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLOUDRAY Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AC Infinity CLOUDRAY Series

Summary of Contents for AC Infinity CLOUDRAY Series

  • Page 1 CLOUDRAY WHOLE HOUSE FAN SYSTEM USER MANUAL USER MANUAL...
  • Page 3 WELCOME Thank you for choosing AC Infinity. We are committed to product quality and friendly customer service. If you have any questions or suggestions, please don’t hesitate to contact us. Visit www.acinfinity.com and click contact for our contact information. EMAIL LOCATION support@acinfinity.com...
  • Page 4 MANUAL CODE CR1907X1 PRODUCT MODEL UPC-A CLOUDRAY T10 AC-CRT10 819137021082 CLOUDRAY T12 AC-CRT12 819137021099 CLOUDRAY T14 AC-CRT14 819137021136 CLOUDRAY T16 AC-CRT16 819137021143 CLOUDRAY T18 AC-CRT18 819137021150 SERIOUS INJURY OR DEATH. Please do not touch the fan's impeller and blades. Secure all nearby objects including wires and cables from coming into contact with the fan’s impeller and blades.

  • Page 5: Manual Index

    Product Contents ................Page 7 Installation Guide ................Page 8 Mounting ..................Page 9 Powering and Setup ..............Page 18 Cleaning ..................Page 20 Controller Programming ..............Page 21 Other AC Infinity Products ............. Page 29 Warranty ..................Page 30...

  • Page 6: Key Features

    KEY FEATURES QUIET PWM MOTOR AUTOMATIC SHUTTERS SMART CONTROLLER PWM-controlled motor features Automatic shutters that open Display with probe enables precise speed control, reduced and close in response to monitoring, thermal & humidity rotor noise, and energy efficient airflow. And closes completely control, fan speed control, EC Voltage.

  • Page 7: Product Contents

    PRODUCT CONTENTS CLOUDRAY WHOLE HOUSE FAN SYSTEM (Included in all series) DUCT FAN DAMPER DUCT SMART SENSOR DUCT SYSTEM BOX & GRILLE TUBE CONTROLLER PROBE CLAMP (x1) (x1) (x1) (x1) (x1) (x2) ROPE CONTROLLER WIRE PROBE DAMPER GRILLE SCREW CLIP SCREW SET MOUNT MOUNT...

  • Page 8: Protective Gear

    INSTALLATION GUIDE PROTECTIVE GEAR Before you begin, make sure to protect yourself from potential injuries by wearing protective gear including: safety goggles to prevent any drywall dust or insulation from getting in your eyes, gloves to avoid direct contact with insulation, and a dust mask to avoid inhaling dust as a result of cutting into the drywall and insulation.
  • Page 9 MOUNTING STEP 1 Before installing the whole house fan, find a location in the hallway or staircase central to Ceiling Joist the home. In the attic, mark the corners using grille plate in between the ceiling joists. Then press each corner with a screwdriver or drill until it reaches the other side.
  • Page 10 MOUNTING STEP 3 Ceiling Check your location and measurements before cutting into the drywall. Use a drywall saw or jigsaw to cut out the marked location. STEP 4 Remove the white grille plate off the damper box. Place the damper box inside the attic vent side down onto the cut hole, as shown in the image.
  • Page 11 MOUNTING STEP 5 Loosely attach the duct tube to the fan to determine the mounting area. Position the fan in an area where you can mount the fan. Remove the duct tube after positioning the fan. As an option you may use the included rope clips to hang your fan from a support beam instead of mounting it.
  • Page 12 MOUNTING STEP 7 Double check to make sure the location is structurally sound and free from obstruction. Use a power drill to drill the four mounting holes. STEP 8 If you are mounting onto anything other than a wood support or stud, insert the included four wall anchors into the drilled mounting holes.
  • Page 13 MOUNTING STEP 9 Position the mounting flanges and align the mounting holes with the wall anchors. Use a screw driver or drill to secure the four wood screws through the mounting frame and into the wall anchors or stud. Make sure the arrow is pointing in your desired direction.
  • Page 14 MOUNTING STEP 11 Secure the motor box back onto the mounting flanges. Make sure the arrow on the motor box points in the same direction as the arrow on the exhaust flange. STEP 12 Connect the duct tube to the intake flange. Secure the duct clamp over the duct tube and tighten it with a flathead screw driver.
  • Page 15 MOUNTING STEP 13 Use the included rope clips to support the duct tube. Clip them onto a nearby beam. If there is no beam or an area to hang the rope clips, secure a nail nearby to hook the rope onto. STEP 14 To tighten the rope, pull the loose end until the duct tube feels secured.
  • Page 16 MOUNTING Ceiling STEP 15 Place the vent onto the dampener through the opening from below the ceiling. STEP 16 Secure the vent using the included four white screws into the drywall. *Note: The screws will only secure the vent to the ceiling drywall.
  • Page 17 MOUNTING STEP 17 Position the controller close to the fan and inside the attic so that the power cord reaches the controller. STEP 18 To mount the controller, use the appropriate screws included for your mounting location.
  • Page 18 POWERING AND SETUP STEP 1 Locate the connector plug of the thermal probe and plug it into the bottom of the thermal controller. STEP 2 Secure the sensor probe head, preferably near the hottest area of the attic. Screw in the square tabs once you find a suitable location.
  • Page 19 POWERING AND SETUP STEP 3 Connect the molex end from the fan into the bottom of the Universal Controller. Be sure to plug it into the left molex 4 pin connector that has the power and fan icon. This plug is meant to power the controller.
  • Page 20 CLEANING STEP 1 Remove the motor box from the mounting flange to remove any dust or build up. Use a damp cloth to clean the dust and dirt off the impeller and fan blades. STEP 2 Clean the dust and dirt off the stator blades on the opposite side.

  • Page 21: Controller Mode

    PROGRAMMING 1. MODE BUTTON 3. LEAF BUTTON 2. UP / DOWN BUTTON Cycles through each of the Adjusts the settings of the Turns the display off controller's modes: ON, OFF, while programs run in the mode that you are in. Up TIMER, AUTO (4 triggers), background.

  • Page 22: Mode Setting

    PROGRAMMING MODE SETTING Pressing the Mode button will cycle through the controller’s available programming modes and settings: ON Mode, OFF Mode, TIMER Mode, AUTO Mode (4 triggers), ALARM Settings (4 settings). ON MODE In this mode, the fans will run continuously regardless of temperature or humidity.
  • Page 23 PROGRAMMING AUTO MODE: HIGH TEMP. In this mode, press the up or down button to set a high temperature trigger. The fans will activate if the probe’s measured temperature exceeds the temperature you have set in this mode. The activated fans will slowly increase in speed until it reaches the speed set in ON Mode.
  • Page 24 PROGRAMMING AUTO MODE: HIGH HUMID. In this mode, press the up or down button to set a high humidity trigger. The fans will activate if the probe’s measured humidity exceeds the humidity you have set in this mode. The activated fans will slowly increase in speed until it reaches the speed set in ON Mode.
  • Page 25 PROGRAMMING ALARM SETTING: HIGH TEMP. In this settings mode, press the up and down button to set a high temperature alarm. The alarm will activate if the probe’s measured temperature exceeds the temperature you have set in this mode. When the alarm triggers, the fan will start spinning gradually to max speed regardless of your other settings.
  • Page 26 PROGRAMMING ALARM SETTING: HIGH HUMID. In this settings mode, press the up and down button to set a high humidity alarm. The alarm will activate if the probe’s measured humidity exceeds the humidity you have set in this mode. When the alarm triggers, the fan will start spinning gradually to max speed regardless of your other settings.
  • Page 27 PROGRAMMING FAHRENHEIT OR CELSIUS To change to displayed units between Fahrenheit and Celsius, set the controller to OFF Mode, then hold the up button for Fahrenheit (°F) or hold the down button for Celsius (°C). DISPLAY BRIGHTNESS To adjust the brightness of the display, set the controller to OFF Mode, then press the up or down button to increase or decrease the brightness level.
  • Page 28 PROGRAMMING ALERT ICONS On the top left of the display is the alert icon section. Icons may flash when the controller wishes to alert you that a particular function or alarm is being triggered. DISPLAY LOCK ALERT This icon is visible when the controller has been locked. The icon will flash to alert you that the controller is locked if you try to change the mode or settings.
  • Page 29 AC INFINITY PRODUCTS Register Booster Fans The AIRTAP series is a line of register booster fans designed to quietly increase airflow coming from your central heat and air conditioning systems, increasing comfort for your home. Features a thermal controller with intelligent programming that will automatically adjust airflow strength in response to heating and cooling temperatures you have set.

  • Page 30: Warranty

    WARRANTY This warranty program is our commitment to you, the product sold by AC Infinity will be free from defects in manufacturing for a period of two years from the date of purchase. If a product is found to have a defect in material or workmanship, we will take the appropriate actions defined in this warranty to resolve any issues.
  • Page 31 No part of the materials including graphics or logos available in this booklet may be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine readable form, in whole or in part, without specific permission from AC Infinity Inc.
  • Page 32 www.acinfinity.com...
