infiNET™ Switches
6 • infiNET Switches: Crestron CLW-SW1/4RF, -SWS1/4RF, -SLVS1RF
Crestron CLW-SW1/4RF, -SWS1/4RF, -SLVS1RF
Physical View of CLW-SW4RF/-SWS4RF (Clockwise from Top; Top, Side, and Front)
1.75 in
(4.45 cm)
2.38 in
(6.03 cm)
3.81 in
(9.68 cm)
3.28 in
(8.32 cm)
(10.48 cm)
RUN SET OFF
The -SLVS1RF is similar in appearance to the -SW1RF and -SWS1RF but does not
have the three-position mode selection switch. The brightness of the LED on the
-SLVS1RF is not programmable.
CLW-SLVS1RF Shown in White
1.88 in
(4.77 cm)
2.70 in
4.13 in
(6.86 cm)
1.50 in
(3.81 cm)
Operations Guide - DOC. 6397
