WeatherTRAK ET Pro3 2-Wire Installation Instructions
Controller Board Design
3.0 Amp Slo-Blow Fuse
24 VAC
Station Expansion Key Ports
4 Flow Sensor(s) Spring Clamp Terminal
4 Common Terminals
4 Master valve Terminals
24 VAC Direct Connect Terminals
Station Program Push Release
Three 2-Wire Connection Terminals
Ground Lug
24 VAC Put for Wireless Rain Sensor (red)
Rain Switch Input
Ribbon Cable Connector
24 VAC
MV1 MV2 MV3 MV4 VC VC
VC VC FL1 FL2 FL3 FL4
4
800.362.8774 • hydropoint.com
© 2019 HydroPoint Data Systems, Inc. All rights reserved.
