WeatherTRAK ET Pro3 2-Wire Installation Instructions

Programming

Programming instructions are also available through our
website at www.hydropoint.com
Menu Screen Number Current Time
Operating Stations
by Program
The following SETUP functions must be performed for the
controller to operate properly. Press the SETUP Menu button.
Press the left or right arrow buttons to move to each function.
Press the plus or minus buttons to change the underlined
value.
Date: Year, Month, Day
Time: Hour (confirm am or pm), minutes
Time Zone: Select your local time zone
Auto Daylight Savings: Automatically updates controller
twice a year, unless you press the button to "No."
Maximum Active Stations: Number of stations physically
wired into the controller.
Stack or Overlap: When Stack is selected, all programs
operate one after another. The start time and water window
for all programs is assigned to Program A. When Overlap is
selected, each program can have its own start time and water
window. See the Owners Manual for more detail.
The following SETUP functions are optional:
Master Valve: Select the type of Master Valve if used.
Assign Pump Start Output: Any station output may be
selected. If a pump start is not required, leave this setting as
Not Assigned.
Runtime Valve Test: Default setting is "Yes". See the
Owner's Manual for more details.
Max Backup ET: Represents the worst-case weekly ET for
your area for the month of July. If you are not sure what this
number should be, call our Customer Service 800 number
for help.
© 2019 HydroPoint Data Systems, Inc. All rights reserved.
HEADER
SCREEN
SPECIFIC DATA
FOOTER
Communicatio n
Status
Note: It is important to select None if a master valve does not
exist. Selecting Normally Open or Normally Closed when you
do not have a master valve may cause a Valve alert that can
prevent irrigation.
Days / Times
In this menu a start time, water window and a water day mode
can be assigned to one of eight available programs A – H. If a
pump start has been assigned as a station output, any one of
three programs can be excluded from a pump start.
Note: Check for STACK or OVERLAP (See SETUP for Stack or
Overlap.): If Stack is set, subsequent programs will have the
same start time as Program A. Programs will run sequentially
starting with program A. If Overlap is set, different start times
may be set for each program.
Exclude a Program from a Pump Start (only when assigned)
Any program can be excluded from a pump start when a
station output has been assigned as a pump start. The
factory default is all programs are assigned to a pump start
unless otherwise selected. This feature might be used when
drip emitters and rotor use the same mainline but only one
sprinkler type needs the added delivery pressure.
