EVAL-1ED020I12F2-DB user guide
Isolated driver daughter board to evaluate 1200 V CoolSiC™ MOSFET
Fehler! Verwenden Sie die Registerkarte 'Start', um Heading 1;Heading1 dem Text
zuzuweisen, der hier angezeigt werden soll.
EVAL-1ED020I12F2-DB
X202
Primary-side
Blockdiagramm of EVAL-1ED020I12F2-DB
Figure 5
The connector X202 (see Figure 5) connects the daughter board with all signals from the primary side (low-
voltage side) of the gate driver, like IN+, IN-, /Fault, /RDY, VCC1 and GND1 of both drivers to the evaluation
platform and the corresponding connector X100 on this platform
As interface to the power switches acting the connectors X200 and X201 (see Figure 5) with the gate signal, the
source connection and the drain connection for the DESAT function. Connector X200 serves the high-side
switch, X201 the low-side switch. At the same time, the respective supply voltages for the drivers ( VCC2, VEE2
and GND2) are connected.
User Guide EVAL-1ED020I12F2-DB
High-side
DESAT
OUT
CLAMP
Low-side
DESAT
OUT
CLAMP
Isolation barrier
8 of 28
X200
D
DESAT
R
DESAT
C
DESAT
VEE2_HS
R
Gate
VCC2_HS
Gate_HS
0
X201
D
R DESAT
DESAT
C
DESAT
VEE2_LS
R
Gate
VCC2_LS
Gate_LS
0
Secondary-side
GND2_HS
GND2_LS
