Crestron C2VEQ-4
Installation and Hookup
Operations & Installation Guide - DOC. 6136
Volume/Equalizer Control Expansion Card
Industry Compliance
As of the date of manufacture, the C2VEQ-4 has been tested and found to comply
with specifications for CE marking and standards per EMC and
Radiocommunications Compliance Labelling (N11785).
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that
may cause undesired operation.
The C2VEQ-4 cards are designed for installation into a dedicated expansion slot on
a 2-Series control system.
The only tools required for installation are a Phillips screwdriver, a grounding strap,
and a grounded workstation.
CAUTION: The C2VEQ-4 and control system contain electro-static discharge
(ESD) sensitive devices. Perform the following procedure while wearing a
grounding strap that is properly grounded and on a grounded workstation to avoid
damaging the C2VEQ-4 and/or the control system.
CAUTION: To prevent stripping of screw heads, threads, or mounting holes, DO
NOT over tighten screws. Tighten only to the specification listed in the individual
step(s).
NOTE: If the C2VEQ-4 is being installed in an AV2, the optional CAGE2 must be
installed before continuing below. For instructions on installing the CAGE2 into an
AV2 control system, refer to the latest revision of the CAGE2 3-Card Expansion
Cage for AV2 Installation Guide (Doc. 5964).
Installation
Follow the instructions below to install the C2VEQ-4 into a 2-Series control system.
1. Disconnect power from the control system.
2. Remove the two screws and blank faceplate from the desired slot in the
control system using a Phillips screwdriver.
3. Align the C2VEQ-4 with the card guides in the open slot and slide the
expansion card into the slot.
4. Firmly press both ends of the C2VEQ-4 faceplate to seat the expansion
card in the control system connector.
5. Hand-tighten the thumbscrews to secure the C2VEQ-4 in position.
6. Reapply power to the control system.
Volume/Equalizer Control Expansion Card: C2VEQ-4 • 5
