Contents CNX MIDI Interface Expansion Card: CNXMIDI Description Functional Description Physical Description Leading Specifications Setup Installation Preparation for Use Programming with SIMPL Windows How the Program Works How to Create the Program Problem Solving Troubleshooting Further Inquiries Return and Warranty Policies... -
Page 5: Cnx Midi Interface Expansion Card: Cnxmidi
THRU interface. Use with devices such as mixers and lighting equipment. Physical Description The CNXMIDI, shown below, is a circuit board fastened to an aluminum faceplate. The card is manufactured to easily fit into an unoccupied slot in a Crestron CNX Generation Control System. CNXMIDI Faceplate (24.89 mm) -
Page 6: Leading Specifications
CE marking. Setup Installation Items required to install the CNXMIDI are already attached to the unit. The only tools required are a Phillips tip screwdriver and a grounding strap. Follow the assembly procedure below. CAUTION: The CNXMIDI contains electrostatic sensitive devices (ESD); observe precautions for handling ESDs to avoid damaging the card. -
Page 7: Preparation For Use
Crestron control system. The next two subsections describe a sample SIMPL Windows program that utilizes the CNXMIDI. The first subsection details how the sample program works with a textual description and block diagram. The second subsection provides a broad description of how to actually create the SIMPL Windows program. -
Page 8: How The Program Works
CRESTRON How the Program Works A basic CNXMIDI SIMPL program is shown in block diagram form below. For this example, the CNXMIDI occupies slot #1 of a CNMSX-PRO. This example plays three notes on a MIDI keyboard. A note is turned on for 0.05s and then there is silence for 0.05s before the next note is played. -
Page 9: How To Create The Program
CNXMIDI to slot #1 of the control system, shown below. NOTE: SIMPL Windows v1.21.03 or later is required to program the CNMSX-AV or PRO with a CNXMIDI card. If using an earlier version of SIMPL Windows, Crestron recommends a SIMPL Windows and operation system upgrade. The latest version can be obtained from the Software Downloads page of Crestron’s website... - Page 10 Graphical Detail View of Oscillator in SIMPL Windows’ Programming Manager Graphical Detail View of Ring Counter in SIMPL Windows’ Programming Manager Graphical Detail View of Set/Reset Latch in SIMPL Windows’ Programming Manager CNX MIDI Interface Expansion Card: CNXMIDI Operations Guide - DOC. 8128...
-
Page 11: Problem Solving
Further Inquiries If after reviewing this Operations Guide for the CNXMIDI, you cannot locate specific information or have questions, please take advantage of Crestron's award winning technical support team by calling: For local support from exclusive Crestron factory-trained personnel call: Operations Guide - DOC. -
Page 12: Return And Warranty Policies
(3) years from the date of shipment to purchaser. Disk drives and any other moving or rotating mechanical parts are covered for a period of one (1) year. CRESTRON warrants all its other products for a period of one year from the defects mentioned above, excluding touchscreen display components which are covered for 90 days.
