- Page 1 Crestron BB-1700CW Wall Mount Back Box for STX-1700CW Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2002 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron BB-1700CW Contents Wall Mount Back Box for STX-1700CW: BB-1700CW Introduction ... 1 Installation ... 2 Installation During Construction ... 2 Installation After Construction ... 5 Further Inquiries ... 9 Future Updates... 9 Appendix: Cutout Detail of Supplied Template ... 10 Return and Warranty Policies ... -
Page 5: Wall Mount Back Box For Stx-1700Cw: Bb-1700Cw
Wall Mount Back Box for STX-1700CW: BB-1700CW Introduction The BB-1700CW back box is wall-mounted hardware that is used to secure the DA-1700CW docking assembly (sold separately). When used with the BB-1700CW, the docking assembly provides operating power, hard-wire communications with a... -
Page 6: Installation
Wall Mount Back Box for STX-1700CW Back Box Enclosure Physical Views and Dimensions Installation There are two different methods of installing the BB-1700CW; installation during construction or post-construction installation. Installation during construction describes installation into a room during construction when the room is framed and the gypsum board has not been hung. - Page 7 (not supplied). 3. Orient the back box enclosure as shown below (notch for manual unlatching upwards) and remove an appropriate knockout for the Cresnet wiring. NOTCH FOR MANUAL ACCESS REMOVED KNOCKOUT Wall Mount Back Box for STX-1700CW: BB-1700CW • 3...
- Page 8 Loosely Install Support Bracket Loosely Secure Enclosure to Mounting Bracket 4 • Wall Mount Back Box for STX-1700CW: BB-1700CW 4. As shown below, loosely install four pan head screws with washers through the inside of the enclosure into the support bracket holes.
-
Page 9: Installation After Construction
(or equivalent), ruler and a #2 Phillips screwdriver. NOTE: This procedure installs the left-side of the back box to the right-side of a framing stud. If installing the back box to the left-side of a stud, reverse the mounting bracket and the mounting support bracket but maintain the orientation of the back box enclosure with the manual unlatching notch at the top. - Page 10 Secure Mounting Bracket to Stud 6 • Wall Mount Back Box for STX-1700CW: BB-1700CW 2. Using a stud finder (or equivalent), locate the right-edge of a stud within the installation area.
- Page 11 Tighten screws only finger-tight so that final adjustments may be made during step 14 of this procedure. 11. Position the back box enclosure near the cut-out area and feed the Cresnet wiring through the enclosure knockout. Wall Mount Back Box for STX-1700CW: BB-1700CW • 7...
- Page 12 Adjust Back Box Clearance and Tighten Bracket Screws CLEARANCE (ALL SIDES) 8 • Wall Mount Back Box for STX-1700CW: BB-1700CW 12. Making sure that the support bracket is behind the gypsum board, position the enclosure into the cutout area. 13. As shown below, loosely install four pan head screws with washers through the inside of the enclosure into the mounting bracket holes.
-
Page 13: Further Inquiries
Crestron BB-1700CW Further Inquiries If after reviewing this Installation Guide for the BB-1700CW, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: Future Updates As Crestron adds improvements to the BB-1700CW, additional information may be made available as manual updates. -
Page 14: Appendix: Cutout Detail Of Supplied Template
Wall Mount Back Box for STX-1700CW Appendix: Cutout Detail of Supplied Template Crestron recommends that the template supplied with the BB-1700CW be used to avoid any error. However, if the template becomes lost or unusable, the dimensions of the cutout area are shown below. -
Page 15: Installation Guide – Doc
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 16 Crestron Electronics, Inc. Installation Guide – DOC. 6105 15 Volvo Drive Rockleigh, NJ 07647 08.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
