- Page 1 Crestron BB-17L Wall Mount Back Box Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.
- Page 3 Wall Mount Back Box: BB-17L Description The BB-17L is a UL TPS-17L wall mounted touchpanel. The BB-17L can also be used with the Isys i/O™ TPMC-17-CH-L and TPMC-17-QM-L wall mounted touchpanels. The table below lists all parts included with the BB-17L.
- Page 4 Wall Mount Back Box The mounted view of the BB-17L is shown in the following diagram. BB-17L Mounted View (Included Cover Plate Attached) 2 • Wall Mount Back Box: BB-17L HOLES FOR STANDARD DRYWALL SCREWS OR NAILS TO MOUNT TO STUD...
-
Page 5: Cover Plate
Crestron BB-17L The dimensions of the BB-17L are shown in the following diagram. Dimensional Drawing (Fully Assembled without Cover Plate) 16.15 in (41.01 cm) BACK BOX (ASSEMBLED) COVER PLATE Installation Guide - DOC. 6367A 12.88 in (32.72 cm) 17.00 in (43.17 cm) -
Page 6: Installation
Required Tools: Complete the following assembly procedure in the order provided (refer to illustration below). Assembly View 4 • Wall Mount Back Box: BB-17L #2 Phillips tip screwdriver • 1. Remove knockouts as required. 2. Attach the supplied #08-8B self-tapping screw to enclosure assembly for grounding. - Page 7 The BB-17L will not fit otherwise. Framing the BB-17L STUD NOTE: The BB-17L can be framed to the right of a stud as shown in the above diagram or to the left. The BB-17L must be mounted to both studs. Required Tools: Installation Guide - DOC.
- Page 8 (IF REQUIRED BY LOCAL BUILDING CODES) 6 • Wall Mount Back Box: BB-17L 1. Frame a space for the BB-17L and required air gaps as shown in the previous diagram. 2. Position the back box to the front edge of the studs and align it as even and as flush as possible.
- Page 9 NOTE: Confirm that the eight tapped holes on the front of the back box are exposed to accept the touchpanel mounting screws. NOTE: Cut the drywall to the inside edge of the front of the back box and notch where needed for the screwholes.
-
Page 10: Other Mounting Option Accessories
This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc. As of the date of manufacture, the BB-17L has been tested and found to comply with specifications for CE marking. Future Updates As Crestron adds improvements to the BB-17L, additional information may be made available as manual updates. -
Page 11: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6367A 15 Volvo Drive Rockleigh, NJ 07647 (2013436) Tel: 888.CRESTRON 11.05 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
