- Page 1 Crestron BB-3000L Wall Mount Back Box Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2002 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron BB-3000L Contents Wall Mount Back Box: BB-3000L Description... 1 Installation ... 3 Assembly ... 3 Mounting ... 4 Other Mounting Option Accessories ... 5 Further Inquiries ... 6 Future Updates... 6 Return and Warranty Policies ... 7 Merchandise Returns / Repair Service ... 7 CRESTRON Limited Warranty... -
Page 5: Wall Mount Back Box: Bb-3000L
Crestron BB-3000L Wall Mount Back Box: BB-3000L Description The BB-3000L is a pre-construction mounting option for the TPS-3000L – Isys™ 6” Lectern/Wall Mounted Touchpanel. The table below lists all parts included with the BB-3000L. Supplied Components The mounted view of the BB-3000L is shown below. -
Page 6: Wall Mount Enclosure
Wall Mount Back Box The dimensions of the BB-3000L are shown below. Dimensional Drawing 2 • Wall Mount Back Box: BB-3000L Crestron BB-3000L 7.90 in (20.07 cm) 10.12 in (25.70 cm) Wall Mount Enclosure 7.84 in (19.91 cm) 10.06 in (25.55 cm) -
Page 7: Installation
QTY. 2 ATTACH BEFORE ATTACHING FRONT MOUTING PLATE #6-32 X 1/4"L SCREW QTY. 8 TOTAL (4 USED FOR FRONT MOUNTING PLATE) #8-32 SELF- TAPPING SCREW FOR GROUND PURPOSES WALL MOUNT ENCLOSURE QTY. 1 Wall Mount Back Box: BB-3000L • 3... -
Page 8: Mounting
1. Position assembly to front edge of stud and align it as even and as flush as possible. 2. Use the level and verify that the back box is horizontal. Leveling must be done before proceeding. 3. Attach the assembly to the left or right side of the stud with standard drywall screws or nails (supplied by other). -
Page 9: Other Mounting Option Accessories
If too much of the cover plate is exposed after the drywall is cut, you may need to patch the area. Crestron provides the following accessories: The manuals for the MMK-3000L and TMK-3000L are available for review from the Downloads | Product Manuals section of the Crestron website (www.crestron.com). Installation Guide - DOC. 6022 5. -
Page 10: Further Inquiries
Wall Mount Back Box Further Inquiries If after reviewing this Installation Guide for the BB-3000L, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: Future Updates As Crestron adds improvements to the BB-3000L, additional information may be made available as manual updates. -
Page 11: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6022 15 Volvo Drive Rockleigh, NJ 07647 10.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
