Crestron DIN-EN Series Installation Manual

DIN-EN Series
Enclosure for DIN Rail Devices
Installation Guide
Description
The DIN-EN series of metal enclosures come in three sizes and house two, three, or six
DIN rails. Each rail accommodates up to 18 DIN units leaving room for one DIN unit of
extra space (18 mm). The extra space provides room for DIN device locking blocks or
wiring along the sides of the enclosure. Each DIN-EN includes a removable front cover
for easy access.
The DIN-EN is perfect for Crestron ® DIN rail products, such as the DIN-AP3, DIN-DALI-2,
and DIN-1DIMU4 (all sold separately). Third-party DIN rail devices can also occupy
space amongst Crestron devices.
Crestron also offers DIN-EN two stage installation products, comprised of rough-in
enclosures and lay-in panels. These products allow for prewiring and rough-in work
during construction and lay-in panel installation later.
Additional Resources
Visit the product page on the Crestron website (www.crestron.com) for additional
information. Use a QR reader application on your mobile device to scan the QR image.
DIN-EN-2X18 DIN-EN-3X18 DIN-EN-6X18
DIN-EN-3X18-MMOE DIN-EN-3X18-MMP DIN-EN-6X18-MMOE DIN-EN-6X18-MMP
Installation
This section shows exterior and interior dimensions of Crestron's DIN-EN products.
External Dimensions of DIN-EN-2X18 Rail Enclosures (Front, Side, and Bottom View)
(16x) Ø 7/8 in (23 mm) knockouts for 1/2 in (13 mm)
conduit (same pattern opposite side)
12-5/16 in
(313 mm)
14-1/8 in
(359 mm)
11-1/2 in
(293 mm)
2-15/16 in
(75 mm)
5 in 1-3/8 in
(127 mm) (35 mm)
3-1/4 in 1-5/16 in
(83 mm) (34 mm)
Internal Dimensions of DIN-EN-2X18 Rail Enclosures
12 in
1-1/16 in
(305 mm)
(27 mm)
Ground bus
10 in
(254 mm)
1-1/16 in
(27 mm) Metal, DIN rail, (4X) Ø 1/4 in
1-3/8 in (35 mm) (Ø 6.4 mm)
wide x Mounting
5/16 in (7.5 mm) holes
high x
13-1/2 in (342 mm)
long (2x)
External Dimensions of DIN-EN-3X18 Rail Enclosures (Front, Side, and Bottom View)
24-1/4 in
(616 mm)
2-1/4 in
(57 mm)
5 in
(127 mm)
16-1/8 in
3-9/16 in
(409 mm)
(91 mm)
Ø 7/8 in (23 mm)
knockouts for
1-5/16 in
1/2 in (13 mm) conduit 1-1/4 in
(34 mm)
(typical both sides)
(32 mm)
2-1/4 in
1/8 in
(58 mm)
(3.2 mm)
1-3/8 in
(35 mm)
2-15/16 in
(75 mm)
~1-1/4 in
4-3/8 in
(32 mm)
(111 mm)
7-3/16 in
(183 mm)
9-11/16 in
(246 mm)
14-3/8 in
(365 mm)
Internal Dimensions of DIN-EN-3X18 Rail Enclosures
3-1/4 in
(83 mm)
(inside)
2-1/4 in
(58 mm)
2-1/8 in
(55 mm)
5-1/2 in
(140 mm)
11/16 in
(19 mm)
3-1/4 in
18-15/16 in
(83 mm)
(482 mm)
(inside)
4 in
(102 mm)
Metal, DIN rail,
1-3/8 in (35 mm)
5/16 in (7.5 mm)
13-1/2 in (342 mm)
1-1/8 in
(28 mm)
knockout
for
3/4 in
(20 mm)
23-1/2 in
conduit
(597 mm)
(typical
both
sides)
3-1/16 in
(78 mm)
1/4 in
(7 mm)
2-1/2 in
3-1/4 in
(64 mm)
(83 mm)
4-7/16 in
(113 mm)
~5/16 in
(24 mm)
External Dimensions of DIN-EN-6X18 Rail Enclosures (Front, Side, and Bottom View)
(2X) Ø 5/16 in
(Ø 8 mm)
Mounting
holes
(2X) Ø 5/8 in
10-7/8 in
(Ø 16 mm)
(276 mm)
Ground bus
5-3/4 in
(147 mm)
(inside)
5-7/8 in
(150 mm)
39-5/8 in
5-7/8 in
(150 mm)
5-3/4 in
(147 mm)
(inside)
(2X) Ø 7/16 in
(Ø 12 mm)
wide x Mounting
holes
high x
long (3x)
2-1/4 in
(58 mm)
~1-1/4 in
(32 mm)
(1 m)
1-1/8 in
(28 mm)
knockout
for
3/4 in
(20 mm)
conduit
(typical
both
sides)
3-1/16 in
(78 mm)
16-1/8 in
(409 mm)
2-1/2 in
Ø 7/8 in (23 mm)
(64 mm)
knockouts for
1/2 in (13 mm) conduit 1-1/4 in
(typical both sides) (32 mm)
~5/16 in
(24 mm)
7-3/16 in
(183 mm)
9-11/16 in
(246 mm)
14-3/8 in
(365 mm)
4 in
(102 mm)
38-7/8 in
(989 mm)
1/4 in
(7 mm)
3-1/4 in
(83 mm)
4-7/16 in
(113 mm)
