CHAPTER 1: OVERVIEW
1.3

Ordering

1.3.1

Order Codes

EPM 6000 MULTI-FUNCTION POWER METERING SYSTEM – USER GUIDE
The order codes for the EPM 6000 are indicated below.
PL6000 –
Base Unit
PL6000
System
Frequency
Current Input
THD and Pulse Output
For example, to order an EPM 6000 for 60 Hz system with a 1 A secondary CT input and no
THD or pulse output option, select order code PL6000-6-1A-0. The standard unit includes
display, all current/voltage/power/frequency/energy counters, percent load bar, RS485,
and IrDA communication ports.
Table 1–2: EPM 6000 Order Codes
* – * – *
EPM 6000 Power Metering System
| | |
50 Hz AC frequency system
5 | |
60 Hz AC frequency system
6 | |
1 A secondary CT
1A |
5A | 5 A secondary CT
0 No THD or pulse output option
THD THD, limit alarms, and 1 KYZ pulse output
1–5
