ICP Family User's Manual

Typical Connection to "TARGET" Connector

1.6
Pin No. Pin Name
1 T_VDD
2 GND
3 T_SCK
4 T_MOSI
5 T_MISO
6 T_VPP
7 T_TARG
8 T_VTEST
9 T_DIO_0
10 T_DIO_1

2 PC-Driven and Standalone Modes

ICP family programmers can be operated in PC-driven and/or standalone mode
Programmer PC-Driven
ICP2/ICP2(HC) Yes
ICP2-GANG Yes (single channel only)
ICP2-Portable Yes
ICP-01 Yes
PC-driven mode means that all programming parameters and data are set in PC and the PC executes
required sequences (programming, verification, blank check, etc)
Standalone mode means that all programming parameters and HEX file data ("Environment") are saved in
programmer's non-volatile flash memory. See paragraph ‎ 1 2 "Preparing Environment and Transferring
Environment to Programmer".
Standalone programming can be activated by 2 ways:
- from PC
- by GO input on the programmer unit (NOTE: optional on ICP2-Portable)
Simultaneous multi-channel programming can be done in standalone mode only
Standard (5-pin) LVP (6-pin)
Programming Programming
PIC10/12/16/18/24 PIC10/12/16/18
dsPIC®/PIC32
VDD VDD
GND GND
CLOCK (PGC) CLOCK (PGC)
DATA (PGD) DATA (PGD)
- -
VPP VPP
- -
- -
- -
- PGM
Standalone
Yes
Yes
Yes
No
PIC17 I2C
VDD VDD
GND GND
CLOCK (PGC) SCL
DATA (PGD) SDA
- -
VPP -
- -
VTEST -
FOSC -
- -
Keeloq®
VDD
GND
CLOCK
DATA
-
-
-
-
-
S1
