ICP Family User's Manual

1 Connectors

"Power" Connector (Power Jack, Center Pin 2.1mm)

1.1
Pin No. Pin Name
(ICP2-GANG)
1/center POWER (+)
2 POWER (-)

"USB" Connector (Type-B Female)

1.2

"RS-232 IN" Connector (D-type 9 Female)

1.3
Note: not available on ICP2-Portable
Pin No. Pin Name
1 -
2 PC_RXD
3 PC_TXD
4 PC_DTR
5 GND
6 12V_OUT
7,8,9 -

"RS-232 OUT" Connector (D-type 9 Male)

1.4
Note: available on ICP2-GANG only
Pin No. Pin Name
1 -
2 CHAIN_232_RXD
3 CHAIN_232_TXD
4 -
5 GND
6,7,8,9 -
Pin Name (ICP2, Voltage Range
ICP2(HC), ICP2-
Portable)
POWER (+/-) 12V to 15V
(9V to 15V for
POWER (+/-)
ICP2-Portable)
Voltage Range Pin Type
- -
RS-232 level RS-232 output
RS-232 level RS-232 input
-15V to +15V Power
- GND
11-14VDC Power
- -
Voltage Range Pin Type
- -
RS-232 level RS-232 input
RS-232 level RS-232 output
- -
- GND
- -
Description
Not connected
TxD output to PC
RxD input from PC
ICP2-GANG: Not connected
ICP2/ICP2(HC): Additional
power supply input
Ground connection
ICP2-GANG: power supply
output
ICP2/ICP2(HC): Not connected
Not connected
Description
Not connected
RxD input from next ICP2-
GANG
TxD output to next ICP2-
GANG
Not connected
Ground connection
Not connected
