ICP Family User's Manual
Save Configuration
Exit

10.2 Edit Menu (Alt-E)

Edit/Fill Program Memory
Edit/Fill Data Memory
Read-only Editors

10.3 Environment (Alt-P)

Save Environment As...
Transfer Environment to Programmer... Transfer Environment (*.pj2) to programmer
Environment Wizard...

10.4 Serialization Menu (Alt-S)

Disable
Load File
Create File

10.5 Device Menu (Alt-D)

Select a type of device to be programmed

10.6 Programmer Menu (Alt-G)

Select Programmer
GANG Configuration
Assign Address to GANG Box
Quick Start Wizard

10.7 Run Menu (Alt-R)

Program
Verify
Blank Check
Read
Program Only

10.8 Communication Menu (Alt-C)

RS-232/USB/Bluetooth COM
Connect

10.9 Options Menu (Alt-O)

Voltage
Clock/Data/MCLR(Advanced)
Preferences
Firmware Upgrade
Activation of Options

10.10 Help Menu (Alt-H)

Read me
About
Save all current settings
Exit the software
Fill an area of the Program Memory with a specified value
Fill an area of the Data Memory (EEPROM) with a specified value
Enable/disable edit of Program and Data Memory buffers
Save current setup and buffers in environment format (*.pj2)
Disable serialization
Load serialization file
Create serialization file
Select programmer (ICP2/ICP2(HC) or ICP2-GANG)
Select active GANG channels (64 max)
Assign address to currently connected programmer (1-16). See
"ICP2-GANG Quick Start" for details
PC-driven mode: program data in the buffer(s) into the device
Standalone mode: activate standalone programming
Verify the data in the device against the data in the buffer(s)
Check the data in the device for the blank state
Read the device and store the data in the buffers
Open a window for repeated programming
Select the desired COM port
Connect to the programmer
Set desired voltages
Set desired Clock/Data/MCLR parameters
Select options for programming
Execute firmware upgrade
Execute activation of optional components:
- DLL/Command Line Support (D)
- dsPIC®/PIC24 Support (P)
- Keeloq® Support (K)
- Secure Programming Support (S)
- PIC32 Support (X)
Note: Contact Softlog Systems for activation details
Display "Readme_w.txt" file
Connect with the programmer and display software and
firmware versions
