ICP Family User's Manual

16 Preferences

16.1 Menu: Options → Preferences

Enables/disables blank check operation before device programming. This option is not useful for flash

devices

When the option is ON the device will be automatically erased by bulk erase mechanism

IMPORTANT:

- this option must be set to ON for proper operation with most of devices

- it's the only option to erase code protected device

When the option is ON the device will be automatically erased by the row erase mechanism

IMPORTANT:

- row erase can't erase a code protected device

- available for dsPIC30 family only, may be useful for operation at low voltages

When the option is ON the DM (EEPROM) is excluded from row erase procedure

NOTE: available for dsPIC30 family only, may be useful to preserve EEPROM

When the option is ON an opcode of the calibration memory is tested during programming

NOTE: available for devices which have a calibration word with movlw/retlw opcode (PIC12F519,

PIC12F675, etc.)

The ICP setup is saved in a configuration file named "icp01.cfg".

IMPORTANT:

the program reads a configuration file that is located in a directory which specified in "Start in"

property. This approach allows creation of unlimited configurations on the same PC

Normally, a configuration file should not be modified by a text editor.

Some parameters can be loaded from the command line:

- hex file to be loaded
