TriangleTube PSRKIT25 Manual

Hx field replacement kit

Advertisement

Quick Links

Quantity
Kit Part
Number
1
PSRKIT01 Heat Exchanger Assembly
1
PTRKIT124 Heat Exchanger Assembly
1
PSRKIT76 Heat Exchanger Assembly
1
PTRKIT125 Heat Exchanger Assembly
1
PSRKIT25 Heat Exchanger Assembly
1
PSRKIT26 Heat Exchanger Assembly
Each Heat Exchanger (HX) Replacement Kit includes
the following items already installed on the heat
exchanger:
- Combustion chamber insulation
- Burner head and gasket
- Sight glass assembly
- Burner mounting plate gasket
Recommended tools:
A. Pipe wrenches
B. Phillips and flat head screw drivers
C. 10 mm socket and/or 10 mm wrench
W RNING
Indicates a potentially hazardous situation
which, if ignored, can result in serious injury
or substantial property damage.
W RNING
For your safety, turn off electrical power sup-
ply at service panel and allow unit to cool
before proceeding to avoid possible electrical
shock and scald hazard. Failure to do so can
cause severe personal injury or death.
W RNING
Use a two wrench method when tightening piping
onto the boiler piping connections.
wrench to prevent the boiler piping from turning /
twisting. Failure to support the boiler piping and
connections in this manner could cause damage to
the boiler and its components.
PRESTIGE Solo
HX Field Replacement
Description
Use one
60, 110, 175 and 250
Kit
X
X
X
The following items are shipped in a PARTS BOX and
must be installed as part of the HX replacement:
- Vent outlet gasket
- Blower gasket
- Boiler piping gaskets
- Long handle phillips head screwdriver
- Long handle T-20 Torx screwdriver
- Igniter, igniter gasket, screws
- Temperature sensors and harness adapters
D. Adjustable wrench
E. Needle nose pliers
F. Diagonal cutting pliers
G. Calibrated combustion analyzer
NOTI E
Indicates special instructions on installation,
operation or maintenance, which are impor-
tant to equipment but not related to personal
injury hazards.
W RNING
Failure to follow instructions below can result
in severe personal injury or damage if ignored.
Instructions are for a qualified installer/
service technician only.
Read all instructions before proceeding.
Follow instructions in proper order.
1
Model
X
X
X
