TriangleTube Prestige Solo 175 Specifications

TriangleTube Prestige Solo 175 Specifications

Fully condensing water boiler
Hide thumbs Also See for Prestige Solo 175:

Advertisement

prestige
Fully Condensing
Water Boiler
Prestige Solo Features
Light weight construction for wall mounting
Approved for zero clearance to combustibles
3" or 4" PVC, CPVC, PP, or AL29-4C venting up to 100
equivalent feet
Limited 10 year warranty on heat exchanger
Approvals
96% AFUE Efficiency
ENERGY STAR Qualified
ANSI Z21.13 and CSA 4.9 Boiler Standards Compliance
ASME Boiler Certification – ASME "H" Stamp
Low NOx operation exceeding SCQMD 2012 regulations
Stainless Steel Fire Tube Heat Exchanger
439 Stainless Steel heat exchanger construction
Low pressure drop minimizes circulator size
High water content provides stable temperature control
Self cleaning flue ways reduce maintenance
Suitable for use with propylene glycol up to 50% concen-
tration.
Project / Location:
Consulting Engineer / Architect:
Mechanical Contractor:
Date 2/15/12
Engineering Submittal
Prestige Solo 175
TriMax Control System
Graphical display with 6 navigation buttons
EZ Setup allows quick and easy boiler settings adjustment
Logging function records sensor readings for system opti-
mization and troubleshooting
Lockout screen includes a text description with basic
troubleshooting information
Outdoor temperature reset to maximize efficiency
Two space heating call inputs with independent outdoor
reset curves
Domestic hot water priority with optional time-out
Integrated cascade control for up to 6 Prestige boilers
0-10 VDC Modulation input
Modbus building management system (BMS) interface
Warm weather shutdown option
Optional boiler freeze protection
Capability to control up to 4 circulators
- Central heating (CH) circulator
- Domestic hot water (DHW) circulator
- Auxiliary boiler circulator
- System circulator
Standard Equipment
Stainless steel premix burner
Direct spark ignition with variable speed blower
Full modulation from 25% to rated input
Automatic air vent
ASME 30 PSI pressure relief valve
Integrated pressure and temperature gauge
Outdoor temperature sensor
Automatic low water cutoff feature
High temperature limit safety control
Line voltage terminal strip with individual fuses
Low voltage terminal strip with removable jumpers for
manual or automatic reset limits
Swing down control panel for easy access and servicing
Alarm contact
Polypropylene condensate pan and internal flue pipe
Polypropylene vent/air connections with test ports
1
Date:
2012-22 Prestige Solo 175 Submittal

Advertisement

loading
Need help?

Need help?

Do you have a question about the Prestige Solo 175 and is the answer not in the manual?

Questions and answers

Summary of Contents for TriangleTube Prestige Solo 175

  • Page 1 Polypropylene condensate pan and internal flue pipe • Suitable for use with propylene glycol up to 50% concen- • Polypropylene vent/air connections with test ports tration. Date: Project / Location: Consulting Engineer / Architect: Mechanical Contractor: Date 2/15/12 2012-22 Prestige Solo 175 Submittal...
  • Page 2: Boiler Specifications

    Volume (gal) Connection Natural or PT175 50 - 170 1 1/4” 3/4” 3” Propane Gas Pressure Drop Curve with Grundfos Circulators Prestige SOLO 175 32.0 Grundfos UP26-99F 28.0 Grundfos UP26-64F Grundfos UPS16-58F/FC - Spd 3 24.0 20.0 16.0 12.0 Flow Rate (GPM)
