CHAPTER 3: DDFR CONFIGURATION
3.3.9 Printing Settings and Actual Values
DISTRIBUTED DIGITAL FAULT RECORDER – INSTRUCTION MANUAL
If the versions are not identical, see Upgrading Settings Files to a
New DDFR Firmware Revision - section 3.2.4 - for details on
changing the Settings File Version.
Fully expand the Settings File.
Click on the Send file to DDFR menu item.
If there are no incompatibilities between the target device and the settings file, the
data will be transferred to the DDFR.
The EnerVista DDFR Setup Software allows you to print partial or complete lists of settings
and actual values. Use the following procedure to print a list of settings:
Select a previously saved Settings File (.DFR) in the Files (Offline)
window.
From the main window menu, select the File > Print Settings menu
item.
The Print dialog box will appear.
Select your print settings as you would normally do.
Click OK.
To preview your DDFR settings before printing them,
CONFIGURING DDFR SETTINGS FILES
63
