CHANGE NOTES
106
Table 6–1: Major updates for DDFR manual revision A2
Page (A1) Page (A2) Change
49 53
49 53
50 55
61 66
62 67
66 72
67 73
68 73
68 74
74
70
77 83
77 83,
78 84
79 85
80-81 32
82 87
90 94
91 95
92 7
Description
Section 3.2.3.1, changed to - Reset DDFR: Click to force a DDFR
system reboot
Section 3.2.3.1, explaination clarified:
Most recent 300-500 events per device, depending on number
of devices configured
Most recent 10-50 waveforms per device, depending on
number of devices configured
Most recent 10-50 Datalogs per device, depending on number
of devices configured
Section 3.2.3.2, 'archived in the Archiver' added to the end of
the sentence
Section 3.4.1, Removed
Section 3.4.3, Removed
Section 4.1.1.2, Double-Click on the Actual Values ->
Waveforms....
'Click on a particular Waveform to open...' added
'Click on one of the folders...' Removed
'Click on one of the Waveform Records listed...' Removed
Section 4.1.1.3, last sentence changed to - '...can be
significantly longer than Waveform Records'
Section 4.1.1.3, changed to 'Double-Click the Actual Values-
>Data Logger tree item'
Section 4.1.1.3, replaced by a new image of Data Logger list
view
Section 4.1.1.4 View Archiver Actual Values - Added
Section 4.2.1, Removed
Section 5.1.1.2
'Internal Watchdog ("health monitor")...' - Removed
'Continual monitoring of the status...' - Removed
'The main interface ...' - Removed
'Capable of archiving...' - Removed
Last paragraph in section 5.1.1.2 - Removed
Section 5.1.2 - new section regarding DDFR archiver
installation is added
Removed
Section 5.2.1, last sentence in brakets is removed
Section 1.4.6, Section 5.2.1.2 moved from Chapter 5 to Chapter
1 as section 1.4.6
Section 5.2.2.1, paragraph Removed
Section 5.3.3.2, instructions and image are modified to reflect
new waveform merge wizard in Archiver
Features not provided in this release, two sections Removed
Figure 1-2, new image with DDFRs named as Substation 1,
Substation 2, Substation 3
