Care of Your Product

• The sensor lens is the most delicate part of the
thermometer and should be kept clean at all
times. Take care when cleaning the lens. Use only a
soft cloth or cotton swab with water or rubbing alcohol.
Allow the lens to dry fully before using
the thermometer.
• Do not submerge any part of the thermometer in water.
Wipe clean with a damp cloth.
• Store the thermometer at room temperature within
32 to 122°F/0 to 50°C.
Precautions
• Dispose of used battery promptly and keep away from
children.
• Keep the batteries and unit away from children.
• Do not clean the case with abrasive or corrosive
compound, which may scratch the plastic and corrode
the electronic circuits.
• Do not subject the unit to excessive force shock,
dust, temperature or humidity, which may result in
malfunction, shorter electronic life span, damaged
battery and distorted parts.
• Do not tamper with the unit's internal components.
Doing so will invalidate the warranty on the unit and
may cause unnecessary battery damage and distorted
parts.
• Do not subject the unit to excessive exposure to direct
sunlight. The unit is not waterproof — do not immerse it
into water or expose to heavy rain.
• To avoid deformation, do not place the unit in extreme
temperatures.
• Do not use the thermometer in a microwave oven.
• Always read the users manual thoroughly before
operating.
CAUTION: Avoid keeping the thermometer too close to
objects that continuously generate high heat for long
periods (i.e., hot plate). This can cause the thermometer
to overheat.
CE Note: This device could be sensitive to electrostatic
discharge. If electrostatic discharge or malfunctioning occurs,
please re-install the battery to reset this unit.

Specifications

Measurement Range
Operating Range
Accuracy,
(Tobj=59-95°F/15-35°C,
Tamb=77°F/25°C)
Accuracy,
(Tamb=73 ±37.4°F/23 ±3°C)
Emissivity Range
Resolution
(14.18 to 392°F/-9.9 to 199.9°C)
Response Time (90%)
Distance:Spot
Power Supply
Battery Life
Dimensions
Weight
-76 to +1022°F/-60to +550°C
32 to 122°F/0 to 50°C
±2.7°F/±1.5°C
Tobj=-76 to +32°F/-60 to 0°C:
±(3.6°F/2°C + 0.05/degree C)
Tobj=32 to 1022°F/0 to 550°C: ±2%
of reading or 4°F/2°C whichever is
greater
0.95 default; adjustable 0.1 to 1,
step .01
0.1°F/0.1°C
1 second
12:1
2 DC 1.5V AAA Alkaline batteries
Typ. 18, min 14 hours continuous use
4.43 W x 5.82 H x 1.63 D
(inches)/112.58 W x 147.93 H x 41.36
D (mm)
5.1 oz/145 g (including batteries –
AAA x 2 pcs)
