VAMP 140
Overcurrent and earth-fault relay
Operation and configuration
instructions
Technical description

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAMP 140 and is the answer not in the manual?

Questions and answers

Related Manuals for VAMP VAMP 140

Summary of Contents for VAMP VAMP 140

  • Page 1 VAMP 140 Overcurrent and earth-fault relay Operation and configuration instructions Technical description...
  • Page 2 VAMP 140 Overcurrent and earth-fault relay VAMP Ltd Operation and Configuration Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 3: Table Of Contents

    6.1.1. Using the VAMPSET program......... 27 6.2. Remote control connections .......... 27 7. Commissioning configuration..........28 7.1. Factory settings ..............28 7.1.1. Configuration during commissioning ....28 7.1.2. Configuration example ......... 29 VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 4 VAMP 140 Overcurrent and earth-fault relay VAMP Ltd Operation and Configuration Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 5: General

    The Mounting and Operation Instructions are published in a separate publication, code named VMMC.EN0xx. 1.1. Relay features The combined overcurrent and earth-fault relay VAMP 140 is a non-directional current measuring protection relay for overcurrent, short-circuit and earth-fault protection. It features the following protection functions: Three overcurrent stages •...

  • Page 6: Operating Safety

    Any operational measure must be carried out according to national and local handling directives and instructions. Carefully read through the relay operation instructions before any relay operational measures are carried out. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 7: User Interface

    Operation and Configuration User interface 2.1. General The VAMP 140 relay can be controlled in three ways: Locally with the push-buttons on the relay front panel • Locally with a PC connected to the serial port on the relay •...

  • Page 8: Display

    VAMP Ltd Operation and Configuration 2.2.1. Display The VAMP 140 relay is provided with a clear 10 character alphanumerical LED display, which normally shows a scrolling text. Use the SERVICE/Setup/Bright menu to set the brightness of the display. The display is dimmed after a preset time.

  • Page 9: Indicators

    Relay operation indicators: Power on auxiliary voltage indicator Error self-supervision fault, the self-supervision output relay operates in parallel with the indicator Alarm starting of protection stage Trip tripping of protection stage VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 10: Local Panel Operations

    5. Push LEFT for at least 2 s to exit from the setting state of a parameter without changing the setting value or, 6. Push ENTER to confirm and store the parameter setting. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...
  • Page 11 VAMP Ltd Overcurrent and earth-fault relay VAMP 140 Operation and Configuration SUBMENUS Figure 3.1-1 The principle of the menu structure and navigation in the menus. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 12: Function Menu Table

    VAMP 140 Overcurrent and earth-fault relay VAMP Ltd Operation and Configuration 3.1.1. Function menu table Figure 3.1.1-1 Main menu of the VAMP 140 relay. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 13: Basic Menu Structure Of Protection Functions

    USER level Use: Parameter values can be read Opening: Level permanently open Closing: Closing not possible OPERATOR level VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 14: Opening Operating Levels

    RIGHT key and then setting the desired digit value using the UP key. 3. Push ENTER. 3.2.2. Changing passwords The set passwords can only be changed using a PC connected to the local RS 232 port on the relay. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 15: Operating Measures

    4.1. Measured data The measured values can be read from the main menu MEASURES menu and its submenus shown in the figure below. Figure 4.1-1 Measures menu of VAMP 140 relay. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 16: Operation Indicators

    2. Acknowledge each event in the alarm list one by one, by pushing ENTER the equivalent times. Then, in the initial display, reset the latched indicators and output relays by pushing the ENTER key. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 17: Reading Of Event Register

    Event list text. Scroll the event list by pushing the UP and DOWN keys. 7. Push the LEFT key twice to move from the event list to the main menu. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 18: Forced Control (Force)

    13. Push the LEFT key to return from the Force: setting state to the Relays submenu. 14. Push the LEFT key to return to the main menu. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 19: Setting Range Limits

    The scroll speed of the text in the display can be adjusted in the SERVICE/Setup/ScrolDelay: menu. 4.7. Setting date and time Date, time and style is set in the SERVICE/Setup/Date, Time and Style menus. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 20: Configuration And Parameter Setting

    Set the Date and time in the SERVICE position of the main • menu, see chapter 5.11. NOTE! Some of the parameters, for instance the password, can only be altered via the RS 232 serial communication port using a PC. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 21: Principle Of Parameter Setting

    5. Use the ENTER key to confirm the function or push the LEFT key for >2 s to cancel the function. 6. Push the LEFT key twice to return to the main menu. Figure 5.1-1 Changing parameters. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 22: Enabling And Disabling Protection Functions (Enable)

    (Io>, Io>>, Io>>> and ArcIo>) Ena CBFP Circuit Breaker Failure Protection stage (CBFP) • RESET Reset the software of the VAMP 140 relay and reset • latches (Reset and Latch) NOTE! Disabling a protection function will remove the item from the menu.

  • Page 23: Configuring Digital Outputs Dout

    Polarity of the input signal (DI1pol), either normally open • (NO) or normally closed (NC) circuit. Remote release of latches using digital input (RemRel) • Selection to event register (OnEvent and OffEvent) • VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 24: Configuring Communication Protocols Com

    IP address of the SNTP Server (NTPSvr) • IP address of the Gateway (Gatew) • IP port number for Protocol (Port) • Local Port Transfer rate of local serial bus (bit/s) • Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 25: Analog Output Ma Output

    Add a link to the recorder (AddLink) • Clear all links (ClrLink) • Manual trigger (MnlTrig) • Count of ready records (ReadyRec) • For list on available links see chapter 2.6 in the technical description. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 26: Service Menu Service

    Setup of screen scroll delay (ScrlDelay) • Changing of password (ChgPwd) • Changing of date, time and date style (Date, Time, • Style) DeviceInfo Serial number of the device (SerN) • Software version (Prgver) • Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 27: Pc Software

    ModBus, SPA-Bus, IEC 60870-5-103, ProfiBus or ModBus TCP can be used as REMOTE communication protocols (see details in Chapter 2.5.2. in technical description). Additional operation instructions for various bus types are to be found in their respective manual. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 28: Commissioning Configuration

    The scaling is done in the software block of the measured signals, Figure 7.1.1-1. Thus the scaling affects all the protection functions. Figure 7.1.1-1 Principle for scaling the measured values of the VAMP 140 relay. 3. Activation of the desired protection functions, ENABLE menu, see Chapter 5.2.

  • Page 29: Configuration Example

    Given within the parenthesis are the configuration menus where the settings are done. Transforming ratios of measurement transformers Current transformer (CT) CTprim 600 A (SCALING) CTsec CToprim 100 A Residual current transformer (CTo) CTosec (SCALING) Ioinp VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 30 DOUT menu, see Chapter 5.5. In the example, relay T1 is programmed to open the circuit breaker with a trip signal (for example I>>) selected in the DOUT menu. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...
  • Page 31 3.9. Three-phase overcurrent protection with two current transformers..............36 3.10. DI controlled overcurrent scaling ......... 36 4. Connections .................38 4.1. Digital input ............... 38 4.2. Auxiliary voltage............... 39 4.3. Output relays ..............39 VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 32 5.3.3. Arc protection (option) ......... 48 5.4. Disturbance Recorder (DR) ..........49 6. Construction .................50 6.1. Dimensional drawing............50 6.2. Panel mounting ..............51 6.3. Semi-flush mounting............51 7. Order information..............52 8. Reference information ............53 Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 33: Introduction

    The modern technology in association with an extensive self- supervision system and a reliable construction ensures an extremely high availability for the VAMP 140 protection relay. The relay is used for overcurrent and earthfault feeder protection. The relay can also be used in other applications where a single-, two- or three-phase protection relay is needed.
  • Page 34 40 - 265 V dc/ac, optionally 24 V dc. Built-in disturbance recorder for evaluating primary and • secondary, as well as neutral currents of the protected object. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 35: Functions

    2.1. Principles of the numerical protection technique The VAMP 140 relay is designed using numerical technology. This means that all signal filtering, protection and control functions are made by digital processing. The numerical technology used in the relay is primarily based...
  • Page 36 Figure 2.1-2 Block diagram of a software based function. 1VUSLOHKO & Start > Event & register Blocking Trip Event & register Setting Delay Enable U>s event Figure 2.1-3 Block diagram of a single-phase protection function. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 37: Relay Protection Functions

    Setting done in xIn Curve Operation charact./ definite time (I>) NI, VI Operation charact./ inverse EI, LTI time (I>) t>, t>>, Operation time t>>> Time multiplier at inverse time (I>) VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 38 2. The fastes possible operating time is about 60 ms at inverse time characteristic according to curve types VI and EI. Figure 2.2.1-2 Block diagram of the three-phase overcurrent stage I>>. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...
  • Page 39 Figure 2.2.1-3 Normal Inverse (IEC 60255-3) characteristic. ⋅ ⎛ ⎞ − ⎜ ⎟ > ⎝ ⎠ t[s] = Trip time = Time multiplier = Measured current I> = I set current VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 40 VAMP 140 Overcurrent and earth-fault relay VAMP Ltd Technical description Figure 2.2.1-4 Very Inverse (IEC 60255-3) characteristic. ⋅ − > (See explanation for symbols under Figure 2.2.1-3) Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...
  • Page 41 Overcurrent and earth-fault relay VAMP 140 Technical description Figure 2.2.1-5 Extremely Inverse (IEC 60255-3) characteristic. ⋅ ⎛ ⎞ − ⎜ ⎟ > ⎝ ⎠ (See explanation for symbols under Figure 2.2.1-3) VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 42 VAMP 140 Overcurrent and earth-fault relay VAMP Ltd Technical description Figure 2.2.1-6 Long Time Inverse (IEC 60255-3) characteristic. ⋅ − > (See explanation for symbols under Figure 2.2.1-3) Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 43: Non-Directional Earth-Fault Protection (50/51N)

    5 A and 1 A, software selection. The earth-fault unit measures the fundamental frequency component Io. In the VAMP 140 relay this means that the degree of attenuation of the third harmonic is at least 60 dB, which contributes to the extremely high accuracy of the earth- fault protection.

  • Page 44: Phase Unbalance Protection I

    The phase unbalance protection operates with definite time characteristic and it is mainly used for signalling. The setting of the phase unbalance protection is performed in the menu called IL SETTING/I2> Set. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 45: Second Harmonic Stage / Inrush (68)

    2ndHarm & > Start & Register event Block Trip & Register event Setting Delay Enable events 2.Harm Figure 2.2.4-1. Block diagram of the second harmonic stage. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 46: Thermal Overload Protection T> (49F)

    τ thermal time constant of cable average RMS value of three measured phase currents natural logarithm preload current (corresponds to the heating level reached) factor for allowed continuous overload rated current Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...
  • Page 47 Alarm Start level set value Heating time constant tau (τ) Fixed value x In Cooling time constant tau2 (τ) Recorded SCntr Start counter (Start) reading values TCntr Trip counter (Trip) reading VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 48: Arc Fault Protection (Option) Arci> (51 L>), Arci > (51N L>)

    (BO) in the output matrix, DO menu. The binary output can be used to forward light information to another relay, e.g. VAMP 140. The binary output can be connected to a maximum of three binary inputs of other relays.
  • Page 49 Selection of the arc sensor sensor channel(s) and/or arc binary input SCntr Recorded Cumulative start counter, only values selected ArcCn arc activations TCntr Cumulative trip counter, only selected ArcCn arc activations VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 50: Circuit-Breaker Failure Protection Cbfp (50Bf)

    Parameters of the circuit-breaker failure protection CBFP (50BF) Parameter: Value/unit: Setting CBRel Relay to be supervised values t> Operation time SCntr Start counter (Start) reading Recorded values TCntr Trip counter (Trip) reading Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 51: Measurement Functions Of The Relay

    • 2.4. Output relay and blocking functions In the VAMP 140 relay all start and trip signals of the protection stages can be freely routed to the output relays and operation indicators according to the requirements of the application. The functions can also be blocked and for this purpose both internal relay signals and external control signals can be used.

  • Page 52: Output Relay Matrix

    For connection to a PC, one RS 232 serial port is available on the front panel of the relay. Any connection to the port is done with the connection cable type VX 003. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 53: Remote Control Connection

    The digital outputs include the Arc binary output information (BO). Recorder capacity is 48 000 bytes. There can be a maximum of 5 recordings and the maximum selection of channels in one recording is 12 (limited in waveform recording). VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 54 Maximum size of recordings Links Connected links Recorder links AddLink Add links ClrLnks Clear links Recorded Status Status of the recorder values Time status Status of the pre-triggering ReadyRec Number of ready records Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 55: Self-Supervision

    If the relay is fully operational with the auxiliary power supply, the IF contact is on the open position. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 56: Application Examples

    The analog mA output can be used to show the load current of one of the phases. The signal can be wired to a local meter or to an automation system Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 57: Overcurrent And Earth-Fault Protection Of An Overhead Line Feeder

    Figure 3.2-1 Three-phase overcurrent protection and earth-fault protection of an overhead line feeder. The earth-fault current is measured with a residual current connection of the current transformers. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 58: Overcurrent, Earth-Fault And Arc Protection Of A Distribution Transformer Feeder

    The binary input of the relay is used for collecting contact alarm signals from, e.g. the distribution transformer Buchholz relay (gas relay) and/or oil level supervision device or the oil temperature alarm contact. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 59: Power Transformer Hv Side Overcurrent And Earth-Fault Protection

    Technical description 3.4. Power transformer HV side overcurrent and earth-fault protection Figure 3.4-1 The VAMP 140 relay used for overcurrent and earth-fault protection of the HV side of a power transformer. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 60: Fast Busbar Short-Circuit Protection Based On Blockings

    70 ms, because the operating time of the start contacts of the overcurrent relays of the outgoing feeders is well under 50 ms. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 61: Circuit-Breaker Failure Protection Via The Output Relay T2

    The digital input is connected in parallel with the trip • contacts (Figure 3.7-1). A resistor module VR10CB enables supervision also when • the circuit breaker is open. The module consist resistor for VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 62 The user may also configure a dedicated digital input event text, e.g. "TRIP CIRCUIT FAILURE", to be displayed on the local display of the protective relay whenever there is a trip circuit failure. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...
  • Page 63 Figure 3.7-1 Trip circuit supervision when the circuit breaker is closed. The supervised circuitry in this CB position is marked with an extra parallel line. The digital input is in active state. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 64 CB position is marked with an extra parallel line. The resistor device VR10CB offers an active input state for the digital input although the open coil auxiliary contact is open. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 65: Complete Protection Of A Hv Capacitor Bank

    3.8. Complete protection of a HV capacitor bank Figure 3.8-1 The VAMP 140 relay is well suited for the complete protection of HV capacitor banks. The three-phase overcurrent stage provides capacitor short-circuit protection (and overload protection). The sensitive earth-fault stage is connected to measure the unbalance current. By utilizing the arc protection features of the relay the capacitor bank can be given selective arc protection.

  • Page 66: Three-Phase Overcurrent Protection With Two Current Transformers

    Press RIGHT key again to enter this menu. • Go to line "Isca: Off" by pressing the UP/DOWN keys. • Press ENTER. The device will ask for an operator • password: Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...
  • Page 67 If the digital input is used for setting control, it should not be used for other purposes like blocking the protection stages. This feature is available starting from software version 2.70 VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 68: Connections

    VAMP Ltd Technical description Connections Figure 2.5.2-1 Connections on the rear panel of the VAMP 140 relay. The VAMP 140 relay is connected to the protected object through the following measuring and control connections: Phase currents IL1, IL2 and IL3 (terminals X1: 1-6) •...

  • Page 69: Auxiliary Voltage

    + = X1:11 and - = X1:12. 4.3. Output relays The VAMP 140 relay is equipped with five configurable output relays and a separate output relay for the self-supervision system Trip relays T1 and T2 (terminals X2: 19 - 20 and 16 - 17) •...

  • Page 70: Arc Protection

    X4: 2 Binary output (BO) X4: 3 GND (connect between relays) X4: 4 Arc sensor 1 + X4: 5 Arc sensor 1 - X4: 6 Arc sensor 2 + X4: 7 Arc sensor 2 - Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 71: Block Diagram

    VAMP Ltd Overcurrent and earth-fault relay VAMP 140 Technical description 4.7. Block diagram Figure 4.7-1 Block diagram of the overcurrent and earthfault relay VAMP 140. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 72: Connection Diagram

    VAMP 140 Overcurrent and earth-fault relay VAMP Ltd Technical description 4.8. Connection diagram Figure 4.8-1 VAMP 140 connection diagram. Relay contact positions when no auxiliary power supply connected. Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 73: Technical Data

    <= 6% near the limits of the voltage range Max. permitted interruption time < 50 ms (110 V dc) 5.1.3. Digital input Number of inputs External control voltage 18 - 265 V ac/dc Burden < 2 mA VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 74: Trip Contacts (T1 And T2)

    IEC-6870-5-103 5.1.8. mA output Number of outputs Output signal 0/1 - 5 mA or 0/4 - 20 mA or any between 0...20mA Load resistance RL < 600 W Accuracy Class 1 Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 75: Arc Option Card

    80 - 1000 MHz, 10 V/m, 80% AM (1 kHz) - GSM test EN 61000-4-3 900 MHz, 10 V/m, pulse modulated 1 MHz burst IEC 60255-22-1 1 kV, differential mode 2,5 kV, common mode Voltage interruption IEC 60255-11 VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 76: Test Voltages

    - Operating time inverse time ±5% or at least ±30 ms (I< 50 x In) *) EI = Extremely Inverse, VI = Very Inverse, NI = Normal inverse, LTI = Long Time Inverse Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 77: Residual Current Protection

    Inverse time characteristic: - 4 characteristic curve sets: (IEC60255- EI, VI, NI, LTI *) - Time multiplier k 0.05 – 3.20 Starting time <60 ms Resetting time <80 ms Resetting ratio 0.97 VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 78: Arc Protection (Option)

    ~ 15 ms Arc sensor channel selection S1, S2, BI, S1/S2, S1/BI, S2/BI, S1/S2/BI Delayed Arc S> Delay time 0.01 – 0.15 Arc sensor channel selection S1, S2, BI, S1/S2, S1/BI, S2/BI, S1/S2/BI Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 79: Disturbance Recorder (Dr)

    1 min Recording time (one record) 0.1 s – 12 000 min (must be shorter than MAX time) Pre trigger rate 0 – 100% Number of selected channels 0 – 12 VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 80: Construction

    VAMP 140 Overcurrent and earth-fault relay VAMP Ltd Technical description Construction 6.1. Dimensional drawing Figure 6.1-1 Dimensional drawing and panel cut-out dimensions Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 81: Panel Mounting

    Technical description 6.2. Panel mounting Figure 6.2-1 Panel mounting 6.3. Semi-flush mounting Figure 6.3-1 Semi-flush mounting Depth with raising frames Type designation VYX078 40 mm 184.0 mm VYX079 60 mm 164.0 mm VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...

  • Page 82: Order Information

    Cable length 3m VX015-3 TTL/RS232 Converter Cable (for 100serie+VEA3CG) Cable length 3m VX008-4 TTL/RS232 Converter Cable ( for Modem MD42, ILPH, ..) Cable length 4m VA 1 DA-6 Arc Sensor Cable length 6m Vamp 24h support phone +358 (0)40 573 6316 VM140.EN011...

  • Page 83: Reference Information

    Fax. Int.+358 (0)6-2121 105 URL: http://www.vamp.fi 24h support phone: Tel . +358 (0)40 573 6316 Email: vampsupport@vamp.fi During office hours 6.00 - 14.00 GMT, please use the following telephone number +358 (0)6-2121 100. VM140.EN011 Vamp 24h support phone +358 (0)40 573 6316...
  • Page 84 We reserve the rights to changes without prior notice VAMP Ltd Street address: Runsorintie 7 Phone: +358 6 212 1100 Post address: Fax: +358 6 212 1105 P.O Box 5, FIN 65381 Vaasa, Internet: www.vamp.fi Finland Email: vamp@vamp.fi VM140.EN011...
